凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (39.110.03) - JACK Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
213 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86617866
|
[1] |
JACK
|
NH
Incl 2 - 11
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Tube, Outer, Incl with 1
|
| 3. |
86590810
|
[1] |
KIT
|
NH
Pin & Chain Superseded by part number: 2047
|
| 5. |
86590811
|
[1] |
KIT
|
NH
Gear
|
| 6. |
86592468
|
[1] |
BEARING ASSY,0.505" ID x 1" OD x 0.344"
|
NH
Bearing
|
| 7. |
86590812
|
[1] |
KIT
|
NH
Crank
|
| 8. |
86590816
|
[1] |
COVER
|
NH
Gearbox
|
| 9. |
280961
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/4" - 20 x 3", Gr 5
|
NH
|
| 10. |
7770
|
[1] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
|
| 11. |
86504104
|
[1] |
LUBE NIPPLE,1/4" x .56" lg, Drive
|
PA
Superseded by part number: 219-14
|
