凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (55.404.01) - LIGHTING Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
539 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Convoluted 3/8" ID, Black Tubing
|
| 2. |
173011
|
[1] |
GROMMET,1” ID x 1.750” OD x .500” Tk
|
NH
|
| 3. |
D121152
|
[2] |
LAMP,12V
|
CAS
Hazard & Turn Signal Lamp, Includes: Ref. 13 & 15
|
| 4. |
D135384
|
[2] |
LAMP,12V
|
CAS
Stop & Tail Lamp, Includes: Ref. 12 & 14
|
| 5. |
84133445
|
[2] |
BRACKET, SUPPORTING
|
NH
Light
|
| 6. |
84225664
|
[1] |
WIRE HARNESS
|
NH
Lighting
|
| 7. |
84292754
|
[9] |
CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL
|
NH
|
| 8. |
263117
|
[7] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 9. |
88612
|
[8] |
WASHER,0.22mm ID x 0.5mm OD x 0.05mm Thk
|
GI
Superseded by part number: 9824326
|
| 10. |
86551278
|
[8] |
SELF-TAP SCREW,HWH, #10 - 16 x 1/2"
|
NH
|
| 11. |
9804257
|
[2] |
FLANGE BOLT,Hex, M6 x 1.0 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 12. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
Lens, Amber
|
| 16. |
87034173
|
[2] |
CABLE TIE,774.7mm L
|
PA
CABLE STRAP Superseded by part number: 529070
|
