神钢零件查询(6D22-T) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (04-004) - STARTER GENERAL 050-110E Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
397 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME057990 | [1] | STARTER MOTOR | KOBASSY, MEC 24V-5.5KW GN050, Serial Range: -GN111A |
| 2. | VAME050939 | [1] | RELAY | KOBSTARTER, MEC, MO ONLY |
| . . | VA3096600091 | [1] | RELAY | KOBM1 ONLY Superseded by part number: 135062A1 |
| 2A. | VAMH005003 | [2] | WASHER | KOBWASHER T=4.5 Superseded by part number: 135079A1 |
| 3. | VAMF140005 | [2] | BOLT | KOBBOLT, FLANGE 6X16 |
| 4. | VAMF100002 | [1] | BOLT 5X10 | |
| . . | VAMF450403 | [1] | WASHER WASHER, SPG 5 | WASHER WASHER, SPG 5 |
| 6. | VAMH000923 | [2] | BOLT | KOBBOLT, FLANGE 12X35 |
| 7. | VAMF407035 | [1] | STUD | KOBSTUD 12X35 |
| 8. | VAMF434106 | [1] | NUT | KOBNUT, FLANGE 12 Superseded by part number: 135085A1 |
| 10. | VA0304450401 | [1] | STRAP | KOBM0 ONLY |
| 21. | VAME059715 | [6] | HEATER | KOBAIR ASSY |
| 23. | VA3093000501 | [6] | GASKET | KOBINLET MANIF Superseded by part number: 134855A1 |
| . . | VAME059760 | [6] | GASKET | KOBW/NET Superseded by part number: VAME353134 |
| 24. | VAME059716 | [5] | WIRE HARNESS | KOB Superseded by part number: 136087A1 |
| 25. | VAME059717 | [1] | STRAP | KOBPLATE, EARTH |
| . . | VAMF450006 | [1] | NUT | KOBWASHER, PLAIN 10 Superseded by part number: 133247A1 |
