纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (90.105.CI[02]) - REAR COVER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
645 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47556091 | [1] | COVER | BUR |
| 2. | 47564167 | [1] | COVER | BUR |
| 3. | 87687101 | [26] | WASHER,10.65mm ID x 31mm OD x 3.3mm Thk | IMO |
| 4. | 9861444 | [26] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | BHB Superseded by part number: 11106031 |
| 5. | 47491428 | [2] | STRIKER PLATE | BUR |
| 6. | 47556096 | [1] | COVER | BUR |
| 7. | 47564171 | [1] | COVER | BUR |
| 9. | 87655042 | [8] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BUR |
| 10. | 43233 | [4] | BOLT,Hex, M10 x 1.25 x 20mm, Cl 8.8, Full Thd | NH |
| 11. | 84469097 | [4] | BUMPER | BUR |
| 12. | 86637931 | [4] | JAM NUT,Jam, 5/16"-18, G5 | FAR |
| 13. | 47556092 | [1] | RH | |
| 14. | 47556097 | [1] | STEP | BURLH |
| 15. | 86639326 | [8] | WASHER,17.3mm ID x 34.5mm OD x 5mm Thk | FAR |
| 16. | 84246776 | [6] | PREV TORQUE BOLT,Hex, M16 x 35mm, Cl 10.9 | BUR |
| 17. | 374835 | [2] | BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd | BHB |
