纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (90.160.CK[01]) - SOUNDPROOFING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
978 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47510558 | [1] | FOAM INSULATION | BURDoor Upper |
| 2. | 47510543 | [1] | PANEL | BURDoor Lower |
| 3. | 84589442 | [1] | INSULATING PANEL | BURRH Side Shield |
| 4. | 84605601 | [1] | INSULATING PANEL | BURRH Upper |
| 5. | 47510557 | [1] | INSULATOR | BURLH Upper |
| 6. | 84589443 | [1] | INSULATING PANEL | BURLH Side Shield |
| 7. | 47510556 | [1] | PANEL | BURLH Door Lower |
| 8. | 84589455 | [2] | INSULATING PANEL | BURLH Lower |
| 9. | 84605603 | [1] | INSULATING PANEL | BURLH Front |
| 10. | 84605604 | [1] | INSULATING PANEL | BURLH Upper |
| 11. | 84605605 | [1] | INSULATING PANEL | BURRH Front |
