纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (5.678[01]) - HYDRAULIC JACK New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
932 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79083656 | [2] | PIN | LEC |
| 2. | 79082636 | [2] | BUSHING | LEC |
| 3. | 79093006 | [1] | CABLE | LEC |
| 4. | 79084977 | [2] | HYDRAULIC HOSE | LEC |
| 5. | 11260211 | [4] | TUBE NUT,M12 x 1.5mm, 8 ZND | LECM24 x 20.5 |
| 6. | 11266411 | [4] | FERRULE,6mm, Style A | LEC |
| 7. | 79113711 | [1] | LEVER | LEC |
| 8. | 76074723 | [1] | HYDRAULIC PUMP | LEC- ASSY |
| 9. | 76074722 | [1] | HYDRAULIC CYLINDER | LEC- ASSY |
| 10. | 8287007 | [2] | LOCK PIN,11.8mm x 94.6mm L | LEC |
| 11. | 4982514 | [1] | CABLE TIE | LEC370 Superseded by part number: 87615202 |
| 12. | 79011405 | [1] | CLAMP | LEC Superseded by part number: 86637995 |
| 13. | 10615779 | [2] | LOCK WASHER,Ext Tooth, M10 | MKT Superseded by part number: 12605671 |
| 14. | 14497331 | [2] | WASHER,25mm ID x 44mm OD x 4mm Thk | LEC24X44 Superseded by part number: 86511328 |
| 15. | 10979231 | [2] | BOLT,Hex, M10 x 16mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87547661 |
| 16. | 13938470 | [2] | ROLL PIN | TTF4X32 |
| 17. | 79068258 | [4] | WASHER | LEC |
