纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (1.211[12]) - TRANSMISSION - CONTROL VALVE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
779 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 79040809 | [2] | PLUG | LEC |
| 3. | 79042389 | [2] | SPRING | LEC |
| 4. | 79042386 | [2] | CAP WASHER | LEC |
| 5. | 79042388 | [2] | SPRING | LEC |
| 6. | 586171 | [2] | PISTON | LEC |
| 7. | 79012577 | [1] | SPRING WASHER | LEC |
| 8. | 11058676 | [2] | SNAP RING,M28, Int | LEC Superseded by part number: 301642, 75210849 |
| 9. | 99434231 | [4] | PLUG | TORM10 x 1.25 |
| 12. | 14453681 | [4] | O-RING,0.07" Thk x 0.801" ID, -19, Cl 7, 75 Duro | LEC Superseded by part number: 5135736 |
| 13. | 14453781 | [2] | O-RING,21.95mm ID x 1.78" Width | MKT(M21.95 ID x 1.78 Thk) Superseded by part number: 5135737 |
| 11. | 14453181 | [1] | O-RING,0.489" ID x 0.07" Width | TTF |
