现代零件查询R200W-7 OSCILLATING CYLINDER(#1149-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
403 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
OSCILLATING CYLINDER
|
|
| . |
31EM-00551BG
|
[1] |
CYLINDER-OSCILLATING
|
|
| 1. |
31EM-00560
|
[1] |
BODY-CYLINDER
|
|
| 2. |
31EM-00570
|
[1] |
ROD-CYLINDER
|
|
| K3. |
Y240-110011
|
[1] |
RING-BUFFER
|
|
| K4. |
Y200-110011
|
[1] |
SEAL-ROD
|
|
| K5. |
Y110-110011
|
[1] |
WIPER-DUST
|
|
| K6. |
Y320-110004
|
[3] |
RING-WEAR
|
|
| K7. |
Y180-110020
|
[1] |
RING-BACK UP
|
|
| 8. |
Y190-126000
|
[1] |
RING-SNAP
|
|
| 9. |
31E3-0038
|
[1] |
SCREW-SET
|
|
| 10. |
31E3-0039
|
[1] |
BALL-STEEL
|
|
| K11. |
S641-110002
|
[1] |
RING-BACKUP,O-RING
|
|
| K12. |
S631-110001
|
[1] |
O-RING
|
|
| K. |
31EM-00545
|
[1] |
SEAL KIT
|
|
