凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (01.41) - POWER TAKE OFF, 540 RPM, CUT-OUT CLUTCH, EUROPE & R.O.W. Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 643 次

Pos.	Part No	Qty	Parts name	Comments
1.	87516690	[1]	PTO	BEL 540 RPM, Cut-Out Clutch, 540 RPM
2.	87517823	[1]	BEARING ASSY	BEL
3.	87517822	[1]	YOKE	BEL
4.	87517824	[1]	YOKE	BEL
5.	87517825	[1]	YOKE	BEL
6.	87517826	[1]	ROLL PIN,10.5mm OD x 95mm L	BEL
7.	87517827	[1]	OUTER SHIELD	BEL
8.	87517828	[1]	INNER SHIELD	BEL Superseded by part number: 87484368
9.	84036368	[1]	ROLL PIN	ZED
10.	87517829	[1]	YOKE	BEL
11.	86979195	[1]	CLUTCH	PA Cutout, 1700 NM
13.	87018244	[1]	CROSS	RAC Superseded by part number: 84355352
14.	87517831	[1]	BEARING COVER,89.4 mm ID x 132 mm OD x 12 mm	BEL
15.	87517832	[1]	BEARING COVER,128.4 mm ID x 187 mm OD x 11 mm	BEL Superseded by part number: 87587199
16.	PL	[12]	PROCURE LOCALLY	BAS Screw, Used to attach Ref. 42 to Ref. 44
17.	86979196	[1]	BEARING,86mm ID x 132mm OD x 12mm H	PA
18.	NSS	[6]	NOT SOLD SEPARAT	CON
19.	87517838	[1]	COLLAR ASSY.	BEL
21.	86979198	[1]	CHAIN,229mm L	PA Safety
22.	849472	[1]	DANGER DECAL	NH English
22.	849483	[1]	DANGER DECAL	NH French
23.	86520950	[1]	DECAL	PA WARNING, PTO Superseded by part number: 47475712
26.	87051166	[1]	SPRING KIT	PA Pack, 1700 Nm
27.	87039014	[1]	PLUG	PA Superseded by part number: 84801514
28.	87039015	[1]	SLEEVE	PA Superseded by part number: 84801513
29.	86625865	[1]	KIT	NH Tapered
35.	87039016	[1]	SNAP RING,M138	PA
36.	87518984	[1]	FRONT PTO ASSY	BEL
37.	87518986	[1]	REAR PTO ASSY	BEL
38.	87518987	[1]	REPAIR KIT	BEL
39.	87018800	[1]	KIT	PA
45.	321204	[4]	LUBE NIPPLE,M6 x 1.0 x 16mm OAL	ZED
46.	933205R91	[1]	LUBE NIPPLE,90 Degree, M8 x 1.25	IH
