凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (01.92[2]) - POWER TAKE OFF, 540 RPM, SLIP CLUTCH, NORTH AMERICA, DRY HAY & SILAGE BALERS, P.I.N. Y8N038894 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
633 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47898154
|
[1] |
PTO
|
NH
540rpm, 1450NM, Incl 2 - 26
|
| 2. |
87517822
|
[1] |
YOKE
|
BEL
|
| 3. |
87517823
|
[2] |
BEARING ASSY
|
BEL
|
| 4. |
87484366
|
[1] |
YOKE
|
PA
|
| 5. |
87517825
|
[1] |
YOKE
|
BEL
|
| 6. |
763847
|
[1] |
PIN
|
CAS
|
| 7. |
47898158
|
[1] |
PTO SHAFT
|
NH
Drive Tube, Outer
|
| 8. |
47898160
|
[1] |
PTO SHAFT
|
NH
Drive Tube, Inner
|
| 9. |
84036368
|
[1] |
ROLL PIN
|
ZED
|
| 10. |
84004288
|
[1] |
YOKE
|
ZED
|
| 11. |
87484371
|
[1] |
PTO CLUTCH
|
PA
|
| 12. |
87685063
|
[1] |
SPIDER
|
PLO
Kit Superseded by part number: ZA105853
|
| 13. |
47898163
|
[1] |
BEARING ASSY
|
NH
|
| 14. |
87517832
|
[1] |
BEARING COVER,128.4 mm ID x 187 mm OD x 11 mm
|
BEL
Shield, Front Superseded by part number: 87587199
|
| 15. |
47898167
|
[1] |
BEARING ASSY
|
NH
|
| 16. |
NSS
|
[6] |
NOT SOLD SEPARAT
|
CON
|
| 17. |
849471
|
[1] |
DANGER DECAL
|
NH
Rotating Driveline
|
| 18. |
849472
|
[1] |
DANGER DECAL
|
NH
Shield Missing
|
| 19. |
87587209
|
[1] |
KIT
|
ZED
Ball Collar
|
| 20. |
86625865
|
[1] |
KIT
|
NH
Taper Pin
|
| 21. |
87012736
|
[8] |
BOLT AND NUT
|
PA
|
| 22. |
47898625
|
[1] |
YOKE
|
NH
Clutch
|
| 23. |
86984909
|
[1] |
BUSHING
|
EML
Superseded by part number: 84026575
|
| 24. |
84011442
|
[1] |
DISC
|
ZED
Superseded by part number: 86517364
|
| 25. |
87484374
|
[1] |
BELLEVILLE SPRING
|
PA
|
| 26. |
47898637
|
[1] |
PTO SHAFT
|
NH
Front, Incl
|
| 27. |
47898638
|
[1] |
PTO SHAFT
|
NH
Rear, Incl
|
| 28. |
47898640
|
[1] |
SHIELD
|
NH
Complete, Incl
|
| 36. |
PL
|
[5] |
PROCURE LOCALLY
|
BAS
Self-Tapping Screw
|
