现代零件查询R200W-7 MAIN CONTROL VALVE(2/5, -#1427)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
563 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 154. |
XJBN-00237
|
[1] |
PLUG
|
|
| 159. |
XJBN-00234
|
[4] |
PLUG
|
|
| 164. |
XJBN-00233
|
[1] |
O-RING
|
|
| 201. |
XJBN-00229
|
[3] |
COVER
|
|
| 203. |
XJBN-00258
|
[2] |
COVER
|
|
| 273. |
XJBN-00210
|
[10] |
SCREW-SOCKET
|
|
| 302. |
XJBN-00843
|
[1] |
SPOOL-ARM 1
|
|
| 302. |
XJBN-00223
|
[1] |
SPOOL-ARM 1
|
|
| 305. |
XJBN-00532
|
[1] |
SPOOL-SWING
|
|
| 307. |
XJBN-00857
|
[1] |
SPOOL-BOOM 2
|
|
| 310. |
XJBN-00853
|
[1] |
SPOOL-TRAVEL
|
|
| 392. |
XJBN-00178
|
[1] |
SPOOL-BY PASS CUT
|
|
| 602. |
XJBN-00162
|
[4] |
PORT RELIEF VALVE
|
|
| 611. |
XJBN-00161
|
[2] |
NEGA-CON RELIEF VLV
|
|
| N551. |
@
|
[2] |
PLUG
|
|
| N561. |
@
|
[2] |
O-RING
|
|
