现代零件查询R200W-7 MAIN CONTROL VALVE(5/5, #1428-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
891 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 154. |
XJBN-00237
|
[1] |
PLUG
|
|
| 164. |
XJBN-00233
|
[1] |
O-RING
|
|
| 165. |
XJBN-00232
|
[14] |
O-RING
|
|
| 166. |
XJBN-00231
|
[5] |
O-RING
|
|
| 168. |
XJBN-00230
|
[1] |
O-RING
|
|
| 169. |
XJBN-00094
|
[1] |
O-RING
|
|
| 202. |
XJBN-00228
|
[1] |
COVER
|
|
| 204. |
XJBN-00257
|
[3] |
COVER
|
|
| 205. |
XJBN-01049
|
[1] |
COVER
|
|
| 209. |
XJBN-00227
|
[2] |
FLANGE
|
|
| 264. |
XJBN-00342
|
[4] |
O-RING
|
|
| 273. |
XJBN-00210
|
[10] |
SCREW-SOCKET
|
|
| 511. |
XJBN-00172
|
[5] |
POPPET
|
|
| 516. |
XJBN-00170
|
[1] |
POPPET
|
|
| 517. |
XJBN-00858
|
[1] |
POPPET
|
|
| 521. |
XJBN-00169
|
[6] |
SPRING
|
|
| 523. |
XJBN-00168
|
[1] |
SPRING
|
|
| 551. |
XJBN-00167
|
[7] |
PLUG
|
|
| 552. |
XJBN-00166
|
[1] |
PLUG
|
|
| 561. |
XJBN-00046
|
[7] |
O-RING
|
|
| 971. |
XJBN-00160
|
[8] |
SCREW-SOCKET
|
|
