纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (3.435[02]) - EQUIPMENT PUMP - COMPONENTS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
882 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76092413 | [1] | ROD | LEC Superseded by part number: 71491108 |
| 2. | 76092414 | [1] | CONTROL | LEC Superseded by part number: 71491109 |
| 3. | 76092415 | [1] | SEAL | LEC |
| 4. | 76092416 | [2] | PIN | LEC |
| 5. | 76092417 | [1] | BODY | LEC |
| 6. | 76092418 | [9] | PLUNGER | LEC |
| 7. | 76092420 | [1] | BEARING,40mm ID x 80mm OD x 23mm W | LEC |
| 8. | 76079293 | [1] | RING | LEC |
| 9. | 76092421 | [1] | SNAP RING | LEC |
| 10. | 76092422 | [1] | SEAL | LEC Superseded by part number: 87603551 |
| 11. | 76092423 | [1] | O-RING,0.139" Thk x 3.484" ID, -238, Cl 5, 75 Duro | LEC Superseded by part number: 87421145 |
| 12. | 76092419 | [1] | SPRING | LEC |
| 13. | 76092424 | [1] | BEARING | LEC |
| 14. | 76092425 | [1] | HYDRAULIC VALVE | LECASSY SEE PAG.3 |
| 15. | 76092426 | [1] | HYDRAULIC VALVE | LECASSY SEE PAG.3 |
| 16. | 76092427 | [1] | HYDRAULIC VALVE | LECASSY SEE PAG.3 Superseded by part number: 71491114 |
| 17. | 71491115 | [1] | PLUNGER | LEC |
| 18. | 76079309 | [1] | SNAP RING | LEC |
| 19. | 76092428 | [1] | SCREW | LEC |
| 20. | 76079305 | [1] | BUSHING | LEC |
| 21. | 76092429 | [1] | O-RING | LEC Superseded by part number: 14460480 |
| 24. | 76079310 | [1] | O-RING,0.07" Thk x 0.239" ID, -10, Cl 5, 75 Duro | LEC Superseded by part number: 49886 |
