纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (3.436[02]) - EQUIPMENT CONTROL VALVE - VERSION (01-02-03) COMPONENTS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
784 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76079110 | [2] | PLUG | LEC |
| 2. | 76092431 | [1] | BODY | LECASSY SEE PAG.4 |
| 3. | 76092432 | [1] | BODY | LEC- ASSY SEE PAG. 5 |
| 4. | 76092433 | [1] | COVER | LEC |
| 5. | 76092434 | [1] | SCREW | LEC Superseded by part number: 87453770 |
| 6. | 76092435 | [5] | HYDRAULIC VALVE | LEC Superseded by part number: 411449A1 |
| 7. | 76092436 | [3] | PLUNGER | LEC Superseded by part number: 8604579 |
| 8. | 72116056 | [3] | SPRING | LEC Superseded by part number: 8604580 |
| 9. | 76092437 | [3] | SCREW | LEC |
| 10. | 76092438 | [2] | SCREW | LEC |
| 11. | 76092439 | [6] | HYDRAULIC VALVE | LECASSY SEE PAG.6 Superseded by part number: 87572321 |
| 12. | 76092440 | [1] | HYDRAULIC VALVE | LECASSY SEE PAG.6 |
| 13. | 76079119 | [1] | PRESSURE RELIEF VALVE | LECASSY; Pressure Relief Valve; SEE PAG.6 |
| 14. | 76079116 | [1] | HYDRAULIC VALVE | LECASSY SEE PAG.6 Superseded by part number: 8602915 |
| 15. | 76092479 | [1] | SCREW | LEC |
| 16. | 76092480 | [1] | HYDRAULIC VALVE | LEC |
| 17. | 76092481 | [1] | BUSHING | LEC |
| 18. | 76092482 | [1] | SCREW | LEC |
| 19. | 76092483 | [1] | SCREW | LEC |
| 20. | 76092484 | [3] | SPRING | LEC |
| 21. | 76092485 | [1] | DOWEL | LEC |
| 22. | 76092486 | [1] | SEAL | LEC |
| 23. | 76092487 | [1] | SEAL KIT | LECSEALS Superseded by part number: 8604575 |
| 38. | 76093023 | [1] | SEAL KIT | LECSEALS |
