斗山零件查询PTO DX235LC-5 Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
931 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
130807-00039
|
[1] |
|
|
| 1. |
130418-00722
|
[1] |
|
|
| 10. |
110951-01824
|
[1] |
|
|
| 11. |
S6510520
|
[1] |
RING;SNAP
|
|
| 12. |
1.430-00024
|
[1] |
COVER
|
|
| 13. |
S8010855
|
[2] |
O-RING 1BG-85
|
|
| 14. |
401002-01709
|
[1] |
|
|
| 15. |
S2208866
|
[8] |
BOLT
|
|
| 16. |
S2212066
|
[2] |
BOLT
|
|
| 17. |
S5010616
|
[4] |
WASHER
|
|
| 18. |
TBD
|
[1] |
|
|
| 2. |
130418-00723
|
[1] |
|
|
| 3. |
130712-01986
|
[1] |
|
|
| 4. |
NA00336
|
[1] |
|
|
| 5. |
430215-01432
|
[1] |
|
|
| 6. |
S5710881
|
[2] |
PIN
|
|
| 7. |
1.109-00026A
|
[2] |
BEARING,BALL
|
|
| 8. |
109-00096
|
[1] |
BEARING;ROLLER
|
|
| 9. |
110951-01823
|
[1] |
|
|
