现代零件查询R200W-7 BOOM CYLINDER(#0615-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
370 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N6-53115
|
[1] |
CYLINDER ASS'Y,RH
|
|
| . |
31N6-53125
|
[1] |
CYLINDER ASS'Y,LH
|
|
| -1. |
31Y1-21605
|
[1] |
BOOM CYL SUB ASSY
|
|
| 1. |
31Y1-20605
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y1-15775
|
[1] |
ROD ASS'Y
|
|
| 3. |
31Y1-20635
|
[1] |
GLAND
|
|
| 4. |
S732-085030
|
[1] |
BUSHING-DU
|
|
| 5. |
Y191-092000
|
[1] |
RING-SNAP
|
|
| K6. |
Y220-085011
|
[1] |
SEAL-ROD
|
|
| K7. |
Y180-085020
|
[1] |
RING-BACK UP
|
|
| K8. |
Y240-085013
|
[1] |
RING-BUFFER
|
|
| K9. |
Y110-085011
|
[1] |
WIPER-DUST
|
|
| 10. |
Y190-099000
|
[1] |
RING-SNAP
|
|
| K11. |
S631-110004
|
[1] |
O-RING
|
|
| K12. |
31YC-BP110
|
[1] |
RING-BACK UP
|
|
| 13. |
31YC-26060
|
[1] |
RING-CUSHION
|
|
| 14. |
31Y1-15815
|
[1] |
PISTON
|
|
| K15. |
Y420-120000
|
[1] |
SEAL-PISTON
|
|
| K16. |
Y310-120000
|
[2] |
RING-WEAR
|
|
| K17. |
Y440-120000
|
[2] |
RING-DUST
|
|
| K18. |
S632-060004
|
[1] |
O-RING
|
|
| K19. |
S642-060003
|
[2] |
RING-BACK UP
|
|
| 20. |
31YC-64030
|
[1] |
NUT-LOCK
|
|
| 21. |
S114-080144
|
[1] |
SCREW-SET,HEX SOC HDLESS
|
|
| 22. |
S109-160804
|
[12] |
BOLT-SOCKET
|
|
| 23. |
31YC-11115
|
[1] |
BUSHING-PIN
|
|
| 24. |
31YC-11245
|
[1] |
BUSH-PIN
|
|
| 25. |
Y000-080200
|
[4] |
SEAL-DUST
|
|
| 26. |
31Y1-22145
|
[1] |
BAND ASSY
|
|
| 26-1. |
31Y1-22155
|
[1] |
BAND SUB ASSY
|
|
| 26-2. |
31YC-32310
|
[1] |
BAND
|
|
| 26-3. |
S071-022730
|
[2] |
U-BOLT
|
|
| 26-4. |
S011-100352
|
[4] |
BOLT-HEX
|
|
| 26-5. |
S201-101002
|
[4] |
NUT-HEXAGON HEAD
|
|
| 26-6. |
S411-100002
|
[8] |
WASHER-SPRING
|
|
| 27. |
31Y1-22165
|
[1] |
PIPE ASSY-R/LH
|
|
| 27. |
31Y1-22175
|
[1] |
PIPE ASSY-R/RH
|
|
| 28. |
31Y1-22180
|
[1] |
PIPE ASSY-B/LH
|
|
| 28. |
31Y1-22190
|
[1] |
PIPE ASSY-B/RH
|
|
| K29. |
Y171-019004
|
[2] |
O-RING
|
|
| 30. |
S107-100454
|
[8] |
BOLT-SOCKET HEAD
|
|
| K. |
31Y1-15885
|
[1] |
SEAL KIT
|
|
