| 1. |
87037949
|
[1] |
SHIELD
|
PA
Includes: Ref. 31
|
| 2. |
87017059
|
[1] |
FLOOR
|
PA
|
| 3. |
84146191
|
[1] |
ANGLE
|
NH
Superseded by part number: 84146192
|
| 4. |
86631554
|
[1] |
CHANNEL
|
NH
|
| 5. |
86631522
|
[1] |
SHEET METAL
|
NH
Stuffer Tool Superseded by part number: 87026611
|
| 6. |
87638749
|
[1] |
DOOR
|
NH
Net, Includes Decals Superseded by part number: 87638750
|
| 7. |
86636528
|
[1] |
BRACKET
|
NH
Superseded by part number: 87015063
|
| 8. |
84135421
|
[1] |
SHIELD
|
NH
|
| 9. |
87564481
|
[1] |
DECAL
|
NH
Net Routing
|
| 10. |
9804255
|
[5] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 11. |
86643976
|
[3] |
ANTI-SKID STRIP
|
NH
Safety, 4" x 56"
|
| 12. |
86507486
|
[5] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
120041
|
[4] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 14. |
86511481
|
[3] |
FLANGE BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
NH
|
| 15. |
86512446
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 16. |
9804258
|
[9] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 17. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 18. |
322357
|
[6] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 19. |
322358
|
[17] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 20. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 21. |
43130
|
[1] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
NH
|
| 22. |
86626584
|
[5] |
BRACKET
|
PA
|
| 23. |
80664
|
[9] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 24. |
9804276
|
[5] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 25. |
9804277
|
[13] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 26. |
9804278
|
[6] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 28. |
86635162
|
[1] |
SHIELD,Rubber Coated
|
NH
|
| 29. |
87019330
|
[1] |
RUBBER SEAL
|
PA
|
| 30. |
86629542
|
[7] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 31. |
86610198
|
[1] |
INSERT,M6 x 1
|
NH
|
| 33. |
87037375
|
[1] |
WARNING DECAL
|
PA
Net Knife, English
|
| 33. |
87037730
|
[1] |
DECAL
|
PA
WARNING, Net Knife, French
|
