凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (08.97[4]) - DECALS, LH, EUROPE & R.O.W. Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
175 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87055490
|
[1] |
DECAL KIT
|
PA
Decal Set, Includes: Decals Shown in Fig. 08.97-3, 08.97-4 & Decal Placement Guide.
|
| 5. |
9846526
|
[4] |
DECAL
|
NH
Tailgate
|
| 6. |
NS
|
[1] |
NOT SERVICED
|
BAS
Model Plate
|
| 13. |
84078384
|
[2] |
DECAL
|
ZED
|
| 19. |
87662330
|
[1] |
DECAL
|
NH
LH Rear Stripe
|
| 23. |
86636717
|
[2] |
DECAL
|
PA
Circle
|
| 24. |
87618576
|
[1] |
DECAL
|
NH
LH, Front Stripe, RB464
|
| 25. |
84004736
|
[2] |
DANGER DECAL
|
ZED
|
| 26. |
84004734
|
[4] |
WARNING DECAL
|
ZED
|
| 27. |
86979306
|
[1] |
EMBLEM
|
PA
CIH Logo
|
| 28. |
730650
|
[1] |
DECAL
|
PA
540 RPM
|
| 29. |
86518436
|
[1] |
WARNING DECAL
|
PA
Superseded by part number: 84004731, 84014115, 84004744, 84004732
|
| 30. |
86642359
|
[1] |
DANGER DECAL
|
PA
Electric Risk
|
| 31. |
84014114
|
[1] |
CAUTION DECAL
|
ZED
|
| 32. |
86643977
|
[3] |
ANTI-SKID STRIP,4” x 40”, Black
|
NH
Safety Step, 4" x 40"
|
| 33. |
86642358
|
[1] |
DECAL
|
PA
Cut
|
| 34. |
86619208
|
[1] |
DECAL
|
NH
Latch Closed
|
| 35. |
86619207
|
[1] |
DECAL
|
NH
Latch Open
|
| 36. |
86619205
|
[1] |
DECAL
|
NH
Bale Size
|
| 37. |
86978512
|
[1] |
DECAL
|
PA
Bale Stop
|
| 38. |
449973
|
[2] |
DECAL
|
NH
|
| 39. |
86642356
|
[1] |
DECAL
|
PA
Net Routing
|
| 40. |
86619595
|
[2] |
DECAL
|
NH
Stripe, White & Black
|
| 41. |
425520
|
[2] |
RIVET,Pop, 3.96mm OD x 10.4mm L
|
NH
Blind, 4 x 10
|
| 42. |
165109
|
[7] |
DECAL
|
NH
Lube Fitting
|
| 43. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
DECAL, Park Brake
|
| 44. |
87037743
|
[3] |
WARNING DECAL
|
PA
Net Knife
|
