现代零件查询R200W-7 PILOT HYD PIPING(CONTROL 4, #0490-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
569 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
@
|
[1] |
RCV SUB ASSY-LH
|
|
| 2. |
@
|
[1] |
RCV SUB ASSY-RH
|
|
| 3. |
@
|
[1] |
ACCELERATOR PEDAL
|
|
| 4. |
@
|
[1] |
RCV LEVER
|
|
| 5. |
@
|
[1] |
CROSS ASSY
|
|
| 6. |
@
|
[1] |
STEERING VALVE
|
|
| 7. |
@
|
[1] |
BRAKE VALVE ASSY
|
|
| 8. |
34EA-30160
|
[1] |
SWITCH-PRESSURE
|
|
| 8. |
31N4-30160
|
[1] |
SWITCH-PRESSURE
|
|
| 8. |
31NA-30160
|
[1] |
SWITCH-PRESSURE
|
|
| 9. |
31L7-40030
|
[1] |
SWITCH-PRESSURE
|
|
| 9. |
31L7-41030
|
[1] |
SWITCH-PRESSURE
|
|
| 9. |
31Q4-40560
|
[1] |
SWITCH-PRESSURE
|
|
| 9. |
31Q4-40840
|
[1] |
SWITCH-PRESSURE
|
|
| 10. |
P392-120000
|
[2] |
WASHER-COPPER
|
|
| 10. |
P392-120000
|
[1] |
WASHER-COPPER
|
|
| 11. |
X410-042024
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 12. |
X410-042026
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 13. |
X410-042028
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 14. |
X410-042036
|
[4] |
HOSE ASSY-ORFS 0X45
|
|
| 15. |
X410-042038
|
[4] |
HOSE ASSY-ORFS 0X45
|
|
| 16. |
X420-042056
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 17. |
X420-042066
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 18. |
31M6-51061
|
[2] |
SHIM(3.2T)
|
|
| 19. |
31E7-0309
|
[1] |
CLAMP-HOSE
|
|
| 20. |
31E7-0312
|
[1] |
CLAMP-HOSE
|
|
| 21. |
X500-110001
|
[2] |
CONNECTOR-ORFS
|
|
| 22. |
X500-110002
|
[4] |
CONNECTOR-ORFS
|
|
| 23. |
X500-310003
|
[2] |
CONNECTOR-ORFS
|
|
| 24. |
X511-104512
|
[2] |
CONNECTOR-LONG,ORFS
|
|
| 25. |
31N5-30050
|
[2] |
CONNECTOR
|
|
| 26. |
31EE-30061
|
[2] |
CONNECTOR
|
|
| 26. |
31EE-30061
|
[1] |
CONNECTOR
|
|
| 27. |
X520-110001
|
[1] |
ELBOW-90,ORFS
|
|
| 28. |
X520-110002
|
[2] |
ELBOW-90,ORFS
|
|
| 29. |
31N6-25060
|
[2] |
FILTER-LAST GUARD
|
|
| 30. |
S035-062026
|
[3] |
BOLT-W/WASHER
|
|
| 31. |
S035-063046
|
[8] |
BOLT-W/WASHER
|
|
| 32. |
S035-083026
|
[4] |
BOLT-W/WASHER
|
|
| 33. |
S035-083526
|
[2] |
BOLT-W/WASHER
|
|
| 34. |
S037-102526
|
[4] |
BOLT-W/WASHER
|
|
| 35. |
S109-100256
|
[4] |
BOLT-SOCKET
|
|
| 36. |
S403-10100B
|
[4] |
WASHER-PLAIN
|
|
| 37. |
S621-011001
|
[19] |
O-RING
|
|
| 37. |
S621-011001
|
[20] |
O-RING
|
|
| 37. |
S621-011001
|
[21] |
O-RING
|
|
| 38. |
S621-012001
|
[2] |
O-RING
|
|
| 39. |
S621-014001
|
[2] |
O-RING
|
|
| 40. |
S631-011004
|
[7] |
O-RING
|
|
| 41. |
S631-014004
|
[8] |
O-RING
|
|
| 42. |
S611-016001
|
[4] |
O-RING
|
|
| 47. |
21E6-30540
|
[1] |
SWITCH-BREAKER
|
|
| 48. |
21NB-00200
|
[1] |
HARNESS-EXT
|
|
| 50. |
X420-042020
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 51. |
X840-515151
|
[2] |
TEE-R/TYPE,SWIVEL,ORFS
|
|
| 52. |
S621-011001
|
[2] |
O-RING
|
|
| 55. |
@
|
[1] |
PEDAL-SINGLE
|
|
| 56. |
X500-110001
|
[1] |
CONNECTOR-ORFS
|
|
| 57. |
31N6-25060
|
[1] |
FILTER-LAST GUARD
|
|
| 58. |
X520-110001
|
[1] |
ELBOW-90,ORFS
|
|
| 59. |
31N6-25110
|
[1] |
ELBOW-90,LONG
|
|
| 60. |
S621-011001
|
[4] |
O-RING
|
|
| 61. |
S631-011004
|
[4] |
O-RING
|
|
| 62. |
S037-103026
|
[2] |
BOLT-W/WASHER
|
|
| 85. |
31N6-39130
|
[1] |
CONNECTOR-TEST
|
|
| 85. |
31N6-39130
|
[2] |
CONNECTOR-TEST
|
|
