| 2. |
87588755
|
[1] |
STEP
|
NH
|
| 3. |
263636
|
[2] |
ANTI-SKID STRIP
|
NH
|
| 4. |
87050286
|
[1] |
STEP
|
PA
|
| 5. |
86640703
|
[1] |
SUPPORT
|
NH
|
| 6. |
27310
|
[1] |
SPRING
|
NH
Superseded by part number: 87047744
|
| 7. |
86642808
|
[1] |
STEP
|
PA
|
| 10. |
86643129
|
[1] |
JACK
|
NH
|
| 11. |
115680
|
[2] |
HOOK
|
NH
|
| 12. |
273672
|
[1] |
FASTENER
|
NH
|
| 15. |
797900
|
[1] |
CHAIN
|
PA
Superseded by part number: 850116
|
| 16. |
86607695
|
[1] |
SPACER,17.48mm ID x 28.6mm OD x 20.6mm L
|
NH
|
| 17. |
87583318
|
[1] |
HITCH
|
BEL
Superseded by part number: 87618465, 87618465, 87618466
|
| 18. |
9826789
|
[1] |
DANGER DECAL,180mm x 90mm H
|
NH
English
|
| 18. |
9827448
|
[1] |
DANGER DECAL
|
NH
French
|
| 22. |
120090
|
[10] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 23. |
120092
|
[1] |
BOLT,M16 x 70mm, Cl 8.8
|
NH
|
| 24. |
86511839
|
[1] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
WIN
|
| 26. |
43140
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 28. |
9706687
|
[6] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 29. |
374895
|
[2] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 30. |
86528652
|
[1] |
WASHER,16.28mm ID x 38.35mm OD x 4mm Thk
|
PA
|
| 31. |
81541
|
[2] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
|
| 32. |
636422
|
[1] |
WASHER,16.66mm ID x 69.85mm OD
|
NH
|
| 33. |
64053
|
[20] |
WASHER,16.9mm ID x 38.55mm OD x 4mm Thk
|
NH
Superseded by part number: 80064053, 86528652
|
| 34. |
130358
|
[2] |
WASHER,16.28mm ID x 38.35mm OD x 4.11mm Thk
|
NH
|
| 37. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 38. |
140046
|
[6] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 41. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 43. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 44. |
9804279
|
[6] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 47. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 48. |
86000441
|
[11] |
NUT,M16 x 2.0, Cl 8
|
NH
|
