| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| -. | 420212-01425 | [-] | ||
| 1. | 420207-00506C | [1] | ||
| 10. | S2212466 | [8] | BOLT | |
| 13. | 120208-00054C | [4] | ||
| 14. | 120804-00080 | [4] | WASHER | |
| 15. | S0563066 | [4] | BOLT | |
| 16. | 180308-00191 | [4] | ||
| 2. | 420207-00507C | [1] | ||
| 3. | 420207-00508B | [1] | ||
| 4. | 420207-00509B | [1] | ||
| 5. | DS2856003 | [2] | O-RING | |
| 6. | S2212666 | [8] | BOLT;SOCKET M10X1.5X50 | |
| 7. | 120208-00073C | [2] | ||
| 8. | 120208-00072C | [2] | ||
| 9. | 2181-9078 | [4] | FLANGE;SPLIT |
