| 1. |
87053969
|
[1] |
ANGLE
|
PA
RH Superseded by part number: 87644263
|
| 2. |
87053968
|
[1] |
BRACKET
|
PA
LH Superseded by part number: 87644262
|
| 3. |
87053661
|
[1] |
BAR
|
PA
Safety, Italy Superseded by part number: 87645231
|
| 3. |
87644264
|
[1] |
PLATE
|
NH
Safety, France
|
| 4. |
87050286
|
[1] |
STEP
|
PA
|
| 5. |
86640703
|
[1] |
SUPPORT
|
NH
|
| 6. |
27310
|
[1] |
SPRING
|
NH
Superseded by part number: 87047744
|
| 7. |
86642808
|
[1] |
STEP
|
PA
|
| 8. |
87588755
|
[1] |
STEP
|
NH
Italy
|
| 8. |
87588754
|
[1] |
STEP
|
NH
France
|
| 9. |
87586081
|
[1] |
SUPPORT
|
NH
|
| 10. |
86643129
|
[1] |
JACK
|
NH
Heavy Duty
|
| 11. |
263636
|
[2] |
ANTI-SKID STRIP
|
NH
|
| 12. |
263117
|
[3] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 13. |
249730
|
[1] |
SECURING STRAP
|
NH
Superseded by part number: 249730F, 249730F, 263117
|
| 14. |
NS
|
[1] |
NOT SERVICED
|
BAS
Shipping Bracket
|
| 15. |
86643543
|
[1] |
HITCH
|
PA
Italy
|
| 15. |
86636673
|
[1] |
HUB
|
NH
France
|
| 19. |
43168
|
[3] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Italy Superseded by part number: 86509867
|
| 19. |
321246
|
[3] |
BOLT,Hex, M16 x 2 x 120mm, Cl 8.8
|
NH
|
| 20. |
86511839
|
[2] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
WIN
|
| 22. |
9804262
|
[8] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 23. |
9804264
|
[2] |
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
|
NH
Superseded by part number: 16587625
|
| 24. |
9670066
|
[6] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 25. |
374895
|
[2] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 27. |
130358
|
[16] |
WASHER,16.28mm ID x 38.35mm OD x 4.11mm Thk
|
NH
Special, Hardened
|
| 28. |
81541
|
[6] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
|
| 30. |
140045
|
[8] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 31. |
140046
|
[6] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 33. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 35. |
9804278
|
[6] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 36. |
9804279
|
[6] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 38. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 39. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 40. |
86000441
|
[16] |
NUT,M16 x 2.0, Cl 8
|
NH
Prevailing Torque
|
