现代零件查询R200W-7 4-OUTRIGGER PIPING 1(INDEPENDENT,#0587-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
235 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
4-OUTRIGGER PIPING 1
|
|
| 3. |
31ER-12010
|
[3] |
SELECTOR VALVE
|
|
| 4. |
31N6-70331
|
[4] |
PIPE ASSY
|
|
| 4. |
31N6-70331BG
|
[4] |
PIPE ASSY
|
|
| 5. |
31N6-70510
|
[2] |
BRACKET-SELECTOR VLV
|
|
| 5. |
31N6-70510BG
|
[2] |
BRACKET-SELECTOR VLV
|
|
| 13. |
P933-067010
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 14. |
P933-067011
|
[4] |
HOSE ASSY-ORFS 0X90
|
|
| 15. |
P933-067012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 16. |
P933-067013
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 19. |
P933-067038
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 20. |
P933-067039
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 21. |
P933-067040
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 22. |
P933-067041
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 23. |
X500-110002
|
[4] |
CONNECTOR-ORFS
|
|
| 26. |
X500-110015
|
[8] |
CONNECTOR-ORFS
|
|
| 26. |
X500-110015
|
[6] |
CONNECTOR-ORFS
|
|
| 29. |
X520-110014
|
[2] |
ELBOW-90,ORFS
|
|
| 31. |
X530-110014
|
[2] |
ELBOW-45,ORFS
|
|
| 32. |
31N6-70530
|
[4] |
ELBOW 45-S/NUT
|
|
| 36. |
P220-110102
|
[4] |
PLUG
|
|
| 37. |
31N6-70540
|
[4] |
FLANGE
|
|
| 38. |
31E4-3030
|
[2] |
CLAMP-PIPE
|
|
| 39. |
31EM-45320
|
[2] |
CLAMP-HOSE
|
|
| 40. |
31EK-70490
|
[2] |
SPACER-CLAMP
|
|
| 41. |
S017-101206
|
[2] |
BOLT-HEX
|
|
| 42. |
S037-102026
|
[4] |
BOLT-W/WASHER
|
|
| 43. |
S037-123026
|
[4] |
BOLT-W/WASHER
|
|
| 44. |
S109-101306
|
[16] |
BOLT-SOCKET
|
|
| 45. |
S205-101006
|
[18] |
NUT-HEX
|
|
| 46. |
S403-101006
|
[18] |
WASHER-PLAIN
|
|
| 47. |
S411-100006
|
[18] |
WASHER-SPRING
|
|
| 49. |
S621-012001
|
[24] |
O-RING
|
|
| 50. |
S621-014001
|
[4] |
O-RING
|
|
| 51. |
S631-011004
|
[4] |
O-RING
|
|
| 52. |
S631-014004
|
[4] |
O-RING
|
|
| 53. |
S631-018004
|
[12] |
O-RING
|
|
| 54. |
S552-102370
|
[20] |
CLAMP-BAND
|
|
| 55. |
Y171-024004
|
[4] |
O-RING
|
|
| 56. |
X511-108523
|
[2] |
CONNECTOR-LONG,ORFS
|
|
