现代零件查询R200W-7 F/DOZER & R/DOZER PIPING 1(#1253-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
963 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[2] |
F/D & R/D
|
|
| 4. |
31N6-70610
|
[2] |
PIPE ASSY
|
|
| 4. |
31N6-70610BG
|
[2] |
PIPE ASSY
|
|
| 5. |
31N6-70620
|
[2] |
PIPE ASSY
|
|
| 5. |
31N6-70620BG
|
[2] |
PIPE ASSY
|
|
| 6. |
31N6-70341
|
[1] |
PIPE ASSY
|
|
| 6. |
31N6-70341BG
|
[1] |
PIPE ASSY
|
|
| 7. |
31N6-70351
|
[1] |
PIPE ASSY
|
|
| 7. |
31N6-70351BG
|
[1] |
PIPE ASSY
|
|
| 10. |
P923-087034
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 11. |
P923-087035
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 14. |
P913-067010
|
[4] |
HOSE ASSY-ORFS 0X0
|
|
| 17. |
P913-047013
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 18. |
X500-110002
|
[4] |
CONNECTOR-ORFS
|
|
| 21. |
X520-110001
|
[3] |
ELBOW-90,ORFS
|
|
| 24. |
P220-110102
|
[2] |
PLUG
|
|
| 26. |
X710-100103
|
[4] |
CAP-HYD,ORFS
|
|
| 28. |
31E4-3030
|
[2] |
CLAMP-PIPE
|
|
| 30. |
31EM-45320
|
[4] |
CLAMP-HOSE
|
|
| 31. |
31EK-70490
|
[2] |
SPACER-CLAMP
|
|
| 33. |
S017-101206
|
[2] |
BOLT-HEX
|
|
| 34. |
S037-102026
|
[4] |
BOLT-W/WASHER
|
|
| 36. |
S205-10100B
|
[2] |
NUT-HEX
|
|
| 37. |
S403-10100B
|
[2] |
WASHER-PLAIN
|
|
| 38. |
S411-100006
|
[2] |
WASHER-SPRING
|
|
| 40. |
S621-014001
|
[8] |
O-RING
|
|
| 41. |
S631-011004
|
[4] |
O-RING
|
|
| 42. |
S631-014004
|
[4] |
O-RING
|
|
| 45. |
S621-011001
|
[2] |
O-RING
|
|
| 46. |
S621-012001
|
[12] |
O-RING
|
|
