| 1. |
87028357
|
[1] |
FLAP
|
PA
|
| 2. |
87378769
|
[1] |
CHAIN,60, 64 Links x 19.05mm = 1219.2mm
|
PA
Roller, RC 60, 64 Pitches, Stuffer Feeder Drive, Includes: (1) Ref. 66
|
| 3. |
87028303
|
[1] |
SHIELD
|
PA
|
| 4. |
86566303
|
[1] |
SPRING
|
NH
|
| 5. |
86628567
|
[1] |
EYEBOLT
|
NH
G2, 3/8"-16 x 8-3/4"
|
| 6. |
87050048
|
[1] |
ROCKER
|
PA
Superseded by part number: 36989
|
| 7. |
86552479
|
[1] |
CHAIN,RC50, 100 Links x 15.88mm = 1587.5mm
|
GI
Roller, Standard Duty, Chrome, RC50, 100 Pitches, Includes: Connector Link 86537460
|
| 8. |
86630851
|
[2] |
SPRING
|
NH
|
| 9. |
87040006
|
[2] |
LINK ASSY.
|
PA
|
| 11. |
87055817
|
[1] |
SHIELD
|
PA
|
| 12. |
86610198
|
[13] |
INSERT,M6 x 1
|
NH
Threaded, M6
|
| 13. |
86626278
|
[1] |
SHIELD
|
PA
Upper, LH
|
| 14. |
87055752
|
[1] |
SHIELD
|
PA
Upper, RH
|
| 15. |
86625649
|
[1] |
SHIELD
|
PA
Lower, RH
|
| 16. |
87041658
|
[1] |
OPEN END WRENCH
|
PA
Superseded by part number: 87050935
|
| 17. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
1.8M Dual Cam Wide Pickup
|
| 18. |
86613200
|
[1] |
IDLER,89mm OD x 47.7mm W
|
NH
Eccentric, Nylon
|
| 19. |
86626383
|
[1] |
SHIELD
|
NH
Lower, LH
|
| 21. |
495-11041
|
[1] |
WASHER,0.406" ID x 0.812" OD x 0.065" W
|
CAS
Superseded by part number: 87016
|
| 23. |
86610200
|
[5] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
| 24. |
705996
|
[2] |
BUSHING
|
NH
7/8" L
|
| 25. |
86632865
|
[2] |
BOLT,444.50mm
|
NH
1/2"-13 x 17-1/2" L
|
| 28. |
614-12040
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 29. |
87638460
|
[1] |
SHIELD
|
NH
|
| 30. |
844-6020
|
[22] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 31. |
9671714
|
[3] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 32. |
844-8020
|
[1] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 33. |
844-10040
|
[2] |
BOLT,Hvy Hex, M10 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 9804263, 87778247
|
| 34. |
9804265
|
[2] |
FLANGE BOLT,Hex, M10 x 60mm, Cl 8.8
|
NH
|
| 35. |
9706703
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 36. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 38. |
844-10030
|
[15] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 39. |
65319
|
[14] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 40. |
495-21044
|
[14] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 41. |
322357
|
[22] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 42. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 43. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 44. |
213404
|
[2] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
|
| 45. |
87020910
|
[2] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
|
| 46. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 48. |
825-2410
|
[1] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 49. |
832-46406
|
[3] |
NUT,M6 x 1, Cl 8
|
CAS
Superseded by part number: 353308
|
| 50. |
425-288
|
[2] |
FLANGE NUT,Flg, 1/2"-13, G5
|
CAS
Superseded by part number: 86544265
|
| 51. |
825-2406
|
[1] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 52. |
825-2408
|
[3] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 53. |
832-46410
|
[4] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 55. |
86631510
|
[2] |
CHAIN,850.9mm L
|
NH
Coil, 33 Links
|
| 56. |
844-8030
|
[4] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 87779272, 9804260
|
| 57. |
832-46412
|
[4] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 58. |
703960
|
[3] |
WASHER
|
NH
1-1/4" OD, Hardened Superseded by part number: 87642988
|
| 59. |
495-21031
|
[15] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 60. |
165109
|
[2] |
DECAL
|
NH
Lube Fitting
|
| 61. |
811-16050
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 2 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 412185
|
| 62. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
Superseded by part number: 87365
|
| 64. |
832-46416
|
[1] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 65. |
86631096
|
[2] |
SPRING NUT
|
NH
Spring
|
| 66. |
86537477
|
[1] |
LINK,19.05mm Pitch
|
NH
|
