现代零件查询R200W-7 D/ACTING MAIN PIPING KIT(ADJUST BOOM)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
564 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
D/ACTING MAIN PIPING
|
|
| 1. |
31EM-91540
|
[1] |
JOINT ASSY-HOSE
|
|
| 2. |
31EM-91620
|
[1] |
JOINT-3 WAY,D/ACT PIPING KIT
|
|
| 3. |
31E9-95010
|
[1] |
BRACKET-3 WAY JOINT
|
|
| 4. |
31N6-94460
|
[1] |
BRACKET-2 SOL VALVE
|
|
| 5. |
P973-166328
|
[2] |
HOSE ASSY-ORFS,FLG 0X90
|
|
| 6. |
31N6-93220
|
[1] |
HOSE ASSY
|
|
| 7. |
P933-166017
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 8. |
P913-163021
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P910-042054
|
[1] |
HOSE ASSY-ORFS
|
|
| 10. |
P910-042056
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 11. |
P910-042058
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 12. |
P910-042060
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 13. |
P910-042082
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 14. |
P930-042042
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 15. |
31N6-92290
|
[1] |
PIPE ASSY
|
|
| 16. |
P173-160104
|
[2] |
FLANGE-HYD,SPLIT
|
|
| 17. |
X500-110001
|
[3] |
CONNECTOR-ORFS
|
|
| 18. |
X500-110013
|
[1] |
CONNECTOR-ORFS
|
|
| 19. |
X500-110021
|
[3] |
CONNECTOR-ORFS
|
|
| 20. |
X520-110001
|
[6] |
ELBOW-90,ORFS
|
|
| 21. |
X520-110012
|
[1] |
ELBOW-90,ORFS
|
|
| 22. |
X520-110005
|
[2] |
ELBOW-90,ORFS
|
|
| 23. |
31N6-25110
|
[2] |
ELBOW-90,ORFS,LONG
|
|
| 24. |
X850-515100
|
[1] |
ELBOW-90,SWIVEL,ORFS
|
|
| 25. |
S631-011004
|
[11] |
O-RING
|
|
| 26. |
S631-014004
|
[2] |
O-RING
|
|
| 27. |
S631-029004
|
[2] |
O-RING
|
|
| 28. |
S631-038004
|
[3] |
O-RING
|
|
| 29. |
S621-011001
|
[15] |
O-RING
|
|
| 30. |
S621-021001
|
[7] |
O-RING
|
|
| 31. |
Y171-024004
|
[2] |
O-RING(AN 계열)
|
|
| 32. |
S109-100306
|
[4] |
BOLT-SOCKET
|
|
| 33. |
S109-100406
|
[4] |
BOLT-SOCKET
|
|
| 34. |
S109-100556
|
[4] |
BOLT-SOCKET
|
|
| 35. |
S109-120656
|
[2] |
BOLT-SOCKET
|
|
| 36. |
S015-080256
|
[4] |
BOLT-HEX
|
|
| 37. |
S017-100256
|
[2] |
BOLT-HEX
|
|
| 38. |
S017-120306
|
[2] |
BOLT-HEX
|
|
| 39. |
S411-080006
|
[4] |
WASHER-SPRING
|
|
| 40. |
S411-100006
|
[2] |
WASHER-SPRING
|
|
| 41. |
S411-120006
|
[2] |
WASHER-SPRING
|
|
| 42. |
21NB-00200
|
[1] |
HARNESS-EXT
|
|
| 43. |
31EM-10060
|
[1] |
PORT RELIEF VALVE
|
|
| 44. |
31EM-10180
|
[1] |
PORT RELIEF VALVE
|
|
| 46. |
21E6-30540
|
[1] |
SWITCH-BREAKER
|
|
| 47. |
31N4-20051
|
[1] |
2-SOLENOID VALVE
|
|
| 47-1. |
XKBL-00015
|
[2] |
VALVE-SOLENOID
|
|
| 47-2. |
XKBL-00004
|
[2] |
COIL
|
|
| 48. |
21N5-10180
|
[1] |
HARNESS-EXT
|
|
