| 1. |
9801618
|
[2] |
QUICK MALE COUPLING,1/2" - 14
|
NH
Male, 1/2"-14 NPTF Superseded by part number: 9412
|
| 2. |
86643512
|
[2] |
HOSE,9.53mm ID x 4699mm L, SAE 100R17
|
NH
|
| 3. |
620019
|
[2] |
CLAMP
|
NH
Double, 11/16" Dia.
|
| 4. |
594116
|
[1] |
CABLE TIE,5/16" W x 21.5" L
|
NH
CABLE STRAP 5/16" x 21-1/2"
|
| 5. |
85006175
|
[1] |
HYDRAULIC VALVE
|
ZED
|
| 6. |
86643513
|
[2] |
HOSE,0.38" ID x 24.00", SAE 100R17
|
NH
|
| 7. |
330346
|
[1] |
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
NH
3/8" Tube, Includes: Ref. 10
|
| 8. |
261066
|
[1] |
ORIFICE,9/16" - 18, 0.813" Orifice
|
NH
.032
|
| 9. |
87029395
|
[1] |
CYLINDER ASSY.,Double Acting, 19.05mm Rod, 119.89mm Stroke
|
PA
Rotor Knife
|
| 10. |
9617873
|
[1] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 11. |
86900514
|
[4] |
ADAPTER
|
PA
|
| 12. |
87017807
|
[2] |
DUST CAP
|
PA
Red Superseded by part number: 333721A1
|
| 13. |
207705
|
[1] |
CLAMP,15.8mm ID
|
NH
|
| 14. |
76350
|
[1] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
Incl Ref 10
|
| 18. |
825-2410
|
[2] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 22. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 25. |
263117
|
[6] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 27. |
86516805
|
[1] |
SOFT TRIM,31-3/4" L
|
NH
Edge Protector
|
| 28. |
86511448
|
[2] |
COTTER PIN,0.148" Dia x 3.31" L
|
NH
9/64" x 3-5/16" Superseded by part number: 80033778
|
| 29. |
86628039
|
[1] |
WIRE HARNESS
|
NH
Rotary Cutter
|
| 30. |
86594422
|
[1] |
SENSOR
|
NH
|
| 31. |
86642946
|
[1] |
BAR
|
NH
|
| 32. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
Switch
|
| 33. |
86616730
|
[1] |
HOLDER
|
NH
|
| 34. |
87036001
|
[15] |
KNIFE
|
PA
Blank
|
| 35. |
844-10025
|
[2] |
BOLT,Hex, M10 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 9804261
|
| 36. |
832-46410
|
[1] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 39. |
86900322
|
[2] |
SCREW,Phillips Drive, Truss HD, #10 - 24 x 1-1/4", SST
|
PA
Truss Hd, Stainless Steel, #10-24 x 1-1/4"
|
| 40. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
Lock, Washer Hd, Stainless Steel, #10-24
|
| 42. |
87389729
|
[1] |
REPAIR KIT
|
PA
Dummy Knife
|
