| | 171-7213Y | [2] | LAMP GP-HEAD(24-VOLT, 65-WATT)(LOW BEAM) | |
| | 171-7214Y | [2] | LAMP GP-HEAD(24-VOLT, 65-WATT)(HIGH BEAM) | |
| | 3E-6466Y | [2] | LAMP GP-SIGNAL(24-VOLT)(FRONT, REAR) | |
| | 162-5402Y | [2] | LAMP GP-SIGNAL(24-VOLT)(FRONT) | |
| | 185-1884Y | [1] | PANEL GP-CIRCUIT BREAKER | |
| | | | S/N AFX301-471 |
| | 214-8896Y | [1] | PANEL GP-CIRCUIT BREAKER | |
| | | | S/N AFX472-1097 |
| | 242-4963Y | [1] | PANEL GP-CIRCUIT BREAKER | |
| | | | S/N AFX1098-1178 |
| | 161-9925Y | [1] | SENSOR GP-PRESSURE(TURBOCHARGER INLET) | |
| | | | S/N AFX1-300 |
| | 194-6722Y | [1] | SENSOR GP-PRESSURE(TURBOCHARGER INLET) | |
| | | | S/N AFX301-471 |
| | 118-7226Y | [1] | SENSOR GP-TEMPERATURE(TORQUE CONVERTER OIL) | |
| | | | S/N AFX1-1097 |
| | 134-2252Y | [1] | SENSOR GP-TEMPERATURE(8-VOLT)(TORQUE CONVERTER OIL) | |
| | | | S/N AFX1098-1178 |
| | 3E-0154Y | [1] | SWITCH GP-MAGNETIC(SECONDARY STEERING RELAY) | |
| | 118-3534Y | [1] | SWITCH GP-MAGNETIC(24-VOLT)(START RELAY) | |
| | | | |
| | 146-0240 | [1] | SWITCH GP-TOGGLE(LOCKING)(HOOD LOCKING) | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 8T-8729 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 185-6094 | [1] | BRACKET AS | |
| | 165-6365 | [1] | FITTING AS | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 7W-7381 | [1] | FITTING-OUTLET | |
| | 6K-8180 | [8] | GROMMET | |
| | 214-5024 | [1] | HARNESS AS-CHASSIS(RH) | |
| | 8T-8729 | [20] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 8T-8737 | [3] | PLUG-SEAL | |
| | 9W-0844 | [1] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 8T-8730 | [20] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [2] | KIT-RECEPTACLE(2-PIN) | |
| | 102-8804 | [1] | KIT-RECEPTACLE(4-PIN) | |
| | 102-8805 | [1] | KIT-RECEPTACLE(6-PIN) | |
| | 102-8806 | [1] | KIT-RECEPTACLE(8-PIN) | |
| | | | (EACH RECEPTACLE KIT INCLUDES RECEPTACLE AS & WEDGE) |
| | 155-2255 | [1] | KIT-CONNECTING PLUG(12-PIN) | |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | 155-2270 | [4] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 9W-0852 | [1] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | | | -OR- |
| | 224-8820 | [1] | HARNESS AS-CHASSIS(RH) | |
| | 9W-0852 | [22] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 8T-8737 | [1] | PLUG-SEAL | |
| | 9W-0844 | [16] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(7-CM) | |
| | 102-8802 | [2] | KIT-RECEPTACLE(2-PIN) | |
| | 102-8804 | [1] | KIT-RECEPTACLE(4-PIN) | |
| | 102-8805 | [1] | KIT-RECEPTACLE(6-PIN) | |
| | 102-8806 | [1] | KIT-RECEPTACLE(8-PIN) | |
| | | | (EACH RECEPTACLE KIT INCLUDES RECEPTACLE AS & WEDGE) |
| | 155-2265 | [1] | KIT-CONNECTING PLUG(8-PIN) | |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | 155-2270 | [3] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 173-4008 | [1] | HARNESS AS-FRONT LIGHTING | |
| | 9W-0852 | [2] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 186-3735 | [6] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 155-2270 | [8] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 102-8806 | [1] | KIT-RECEPTACLE(8-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 186-3736 | [16] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 2L-8075 | [4] | TERMINAL-RING(14-GA TO 16-GA, NO. 8 SCREW) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(13-CM) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(20-CM) | |
| | | | -OR- |
| | 244-8719 | [1] | HARNESS AS-FRONT LIGHTING | |
| | 9W-0852 | [8] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 9W-0844 | [20] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(13-CM) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(20-CM) | |
| | 102-8806 | [1] | KIT-RECEPTACLE(8-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 155-2270 | [10] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 173-4006 | [1] | HARNESS AS-HOOD(FUEL TANK) | |
| | 102-8804 | [1] | KIT-RECEPTACLE(4-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | 155-2270 | [1] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2274 | [1] | KIT-CONNECTING PLUG(6-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 8N-1540 | [1] | PIN-CONNECTOR(12-GA TO 14-GA) | |
| | 8T-8729 | [4] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0852 | [2] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 129-7163 | [1] | PLUG AS-CONNECTOR(1-PIN) | |
| | 129-7164 | [1] | RECEPTACLE AS-CONNECTOR(1-PIN) | |
| | 8N-1541 | [1] | SOCKET-CONNECTOR(12-GA TO 14-GA) | |
| | 8T-8730 | [6] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0844 | [5] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 3T-4696 | [1] | TERMINAL-RING(10-GA TO 12-GA, 7/16-IN SCREW) | |
| | 2L-8079 | [1] | TERMINAL-RING(14-GA TO 16-GA, 3/8-IN SCREW) | |
| | | | -OR- |
| | 239-2953 | [1] | HARNESS AS-HOOD | |
| | 8N-1540 | [1] | PIN-CONNECTOR(12-GA TO 14-GA) | |
| | 186-3735 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0852 | [2] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 129-7163 | [1] | PLUG AS-CONNECTOR(1-PIN) | |
| | 129-7164 | [1] | RECEPTACLE AS-CONNECTOR(1-PIN) | |
| | 8N-1541 | [1] | SOCKET-CONNECTOR(12-GA TO 14-GA) | |
| | 9W-0844 | [4] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 186-3736 | [7] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(7-CM) | |
| | 102-8804 | [1] | KIT-RECEPTACLE(4-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | 155-2270 | [1] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2274 | [1] | KIT-CONNECTING PLUG(6-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 174-9970 | [1] | HARNESS AS-POWER(ALTERNATOR) | |
| | 8T-8827 | [1] | BOOT(RED) | |
| | 8N-1548 | [1] | PIN-CONNECTOR(4-GA) | |
| | 9X-3401 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 127-5484 | [1] | RECEPTACLE AS-CONNECTOR(1-PIN) | |
| | 9W-0844 | [2] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 186-3736 | [14] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 9X-4997 | [1] | TERMINAL AS | |
| | 9X-4998 | [1] | SOCKET(14-GA TO 16-GA) | |
| | 9G-4343 | [1] | TERMINAL-RING(4-GA, 1/4-IN SCREW) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(10-CM) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 155-2265 | [1] | KIT-CONNECTING PLUG(8-PIN) | |
| | 155-2270 | [4] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 174-9971 | [1] | HARNESS AS-REAR CHASSIS | |
| | 4S-6679 | [2] | ADAPTER | |
| | I | [1] | HOSE AS |
| | 8T-8730 | [18] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0844 | [2] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 155-2271 | [2] | KIT-CONNECTING PLUG(4-PIN) | |
| | 155-2274 | [2] | KIT-CONNECTING PLUG(6-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 173-4010 | [1] | HARNESS AS-SOLENOID(HYDRAULIC FAN) | |
| | 8T-8730 | [4] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 155-2270 | [2] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | | | -OR- |
| | 214-5025 | [1] | HARNESS AS-SOLENOID(HYDRAULIC FAN) | |
| | 8T-8730 | [4] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 155-2270 | [2] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 224-8819 | [1] | HARNESS AS-TRANSMISSION | |
| | 8N-1521 | [1] | BELL AS-END | |
| | 9W-0852 | [8] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 8N-1514 | [1] | PLUG AS-CONNECTOR(37-PIN) | |
| | 9X-4391 | [1] | PLUG AS-CONNECTOR(70-PIN) | |
| | 155-2265 | [1] | KIT-CONNECTING PLUG(8-PIN) | |
| | 155-2270 | [4] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 8T-8737 | [21] | PLUG-SEAL | |
| | 7G-7917 | [9] | PLUG-SEAL | |
| | 102-8806 | [1] | KIT-RECEPTACLE(8-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 9X-6857 | [28] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 186-3736 | [29] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0844 | [36] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 9X-6772 | [1] | STRAP-CABLE | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(15-CM) | |
| | | | -OR- |
| | 250-0719 | [1] | HARNESS AS-TRANSMISSION | |
| | 8N-1521 | [1] | BELL AS-END | |
| | 9W-0852 | [8] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 186-3735 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 8N-1514 | [1] | PLUG AS-CONNECTOR(37-PIN) | |
| | 9X-4391 | [1] | PLUG AS-CONNECTOR(70-PIN) | |
| | 8T-8737 | [23] | PLUG-SEAL | |
| | 7G-7917 | [9] | PLUG-SEAL | |
| | 9X-6857 | [28] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 186-3736 | [28] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0844 | [37] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 9X-6772 | [1] | STRAP-CABLE | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(15-CM) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | 102-8806 | [1] | KIT-RECEPTACLE(8-PIN) | |
| | | | (EACH RECEPTACLE KIT INCLUDES RECEPTACLE AS & WEDGE) |
| | 155-2265 | [1] | KIT-CONNECTING PLUG(8-PIN) | |
| | 155-2270 | [5] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 7T-0969 | [1] | HORN AS(24-VOLT, LOW TONE) | |
| | 8C-7581M | [2] | SCREW-MACHINE(M4X0.7X8-MM) | |
| | 9B-7233 | [2] | LOCKWASHER | |
| | 096-6166 | [2] | WASHER-HARD(4.5X9X1-MM THK) | |
| | | | -OR- |
| | 163-1201 | [1] | HORN AS(24-VOLT, LOW TONE) | |
| | 177-9853 | [1] | RECEPTACLE AS(2-PIN) | |
| | 178-3586 | [1] | LOCK | |
| | 7T-0970 | [1] | HORN AS(24-VOLT, HIGH TONE) | |
| | | | -OR- |
| | 174-7875 | [1] | HORN AS(24-VOLT, HIGH TONE) | |
| | 177-9853 | [1] | RECEPTACLE AS(2-PIN) | |
| | 178-3586 | [1] | LOCK | |
| | 177-7168 | [1] | PLATE AS | |
| | 177-7169 | [1] | PLATE AS | |
| | 184-4579 | [1] | PLATE AS | |
| | 184-5272 | [1] | PLATE AS | |
| | 232-1067B | [1] | PLUG AS-CODE | |
| | 162-7268B | [1] | PLUG AS-CODE | |
| | 149-2612 | [1] | RELAY AS(24-VOLT)(HOOD TILT MOTOR) | |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0852 | [4] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 102-8805 | [1] | KIT-RECEPTACLE(6-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 106-8704 | [2] | SUPPRESSOR AS-ARC | |
| | | | (EACH INCLUDES) |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 3E-6450 | [1] | SWITCH AS-PRESSURE(STEERING OIL) | |
| | 8T-8729 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 114-5333 | [1] | SWITCH AS-PRESSURE(HIGH LOW)(AIR CONDITIONER) | |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 172-7073 | [1] | SWITCH AS-PRESSURE(PARKING BRAKE) | |
| | 8T-8729 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 8T-5677D | | SLEEVE(0.6-M) | |
| | | | -OR- |
| | 213-6947 | [1] | SWITCH GP-PRESSURE(PARKING BRAKE) | |
| | 5P-6008D | | TUBE-HEAT SHRINK(6.35-MM DIA)(0.2-M) | |
| | 186-3735 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 3E-6449 | [1] | SWITCH AS-TEMPERATURE(OUTPUT TRANSFER GEAR) | |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | | | |
| | 5C-9553M | [8] | BOLT(M6X1X16-MM) | |
| | 8T-4138M | [5] | BOLT(M6X1X20-MM) | |
| | 8T-4139M | [2] | BOLT(M12X1.75X30-MM) | |
| | 8T-4189M | [6] | BOLT(M8X1.25X20-MM) | |
| | 8T-4197M | [1] | BOLT(M8X1.25X40-MM) | |
| | 8T-6466M | [1] | BOLT(M10X1.5X60-MM) | |
| | 8T-4136M | [23] | BOLT(M10X1.5X25-MM) | |
| | 8T-4137M | [29] | BOLT(M10X1.5X20-MM) | |
| | 8T-4195M | [6] | BOLT(M10X1.5X30-MM) | |
| | 8T-4196M | [2] | BOLT(M10X1.5X35-MM) | |
| | 8T-4200M | [2] | BOLT(M8X1.25X16-MM) | |
| | 184-4574 | [1] | BRACKET | |
| | 184-4575 | [1] | BRACKET | |
| | 6U-2703 | [2] | BRACKET-ANGLE | |
| | 184-4576 | [1] | BRACKET-MOUNTING | |
| | 184-4577 | [1] | BRACKET-MOUNTING | |
| | 3S-8665 | [3] | CLIP(LOOP) | |
| | 4P-7581 | [6] | CLIP(LADDER) | |
| | 4P-8134 | [6] | CLIP(LADDER) | |
| | 5P-9085 | [14] | CLIP(LOOP) | |
| | 6D-3479 | [12] | CLIP(LOOP) | |
| | 6D-4246 | [6] | CLIP(LOOP) | |
| | 7C-4354 | [17] | CLIP | |
| | 8M-2770 | [1] | CLIP(LOOP) | |
| | 124-0174 | [3] | CLIP(LOOP) | |
| | 5P-7854 | [1] | CLIP(LOOP) | |
| | 8M-2773 | [1] | CLIP(LOOP) | |
| | 9M-4972 | [1] | CLIP(LOOP) | |
| | 9M-8406 | [2] | CLIP(LOOP) | |
| | 2V-2043 | [1] | NUT-BULKHEAD(1-5/8-12-THD) | |
| | 5C-2890M | [17] | NUT(M6X1-THD) | |
| | 5C-7261M | [1] | NUT(M8X1.25-THD) | |
| | 8T-4133M | [20] | NUT(M10X1.5-THD) | |
| | 116-8247 | [1] | PLATE-INSTRUCTION(HOOD TILT) | |
| | 3J-1907 | [3] | SEAL-O-RING | |
| | 3K-0360 | [2] | SEAL-O-RING | |
| | 9X-7378 | [1] | SEAL-O-RING | |
| | 6H-7127 | [1] | SPACER(13/32X5/8X9/16-IN THK) | |
| | 069-4447 | [1] | SPACER(12.45X19.01X28.6-MM THK) | |
| | 6L-7008 | [101] | STRAP-CABLE | |
| | 7K-1181 | [19] | STRAP-CABLE | |
| | 9X-8256 | [15] | WASHER(6.6X12X2-MM THK) | |
| | 5P-4115 | [3] | WASHER-HARD(7.2X19X2-MM THK) | |
| | 8T-4224 | [10] | WASHER-HARD(8.8X16X2-MM THK) | |
| | 8T-4121 | [80] | WASHER-HARD(11X21X2.5-MM THK) | |
| | 8T-4205 | [12] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| | 8T-4223 | [2] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| | 149-7889 | [1] | WIRE AS | |
| | B | | USE AS REQUIRED |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
