纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.523[01]) - RIPPER (RP) - 'RECO' - OPTIONAL CODE 784117041 - VERSION (01-02-04) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
540 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76089259 | [1] | SUPPORT | LEC Superseded by part number: 76031588 |
| 2. | 76031589 | [4] | LOCK PIN | LEC |
| 3. | 12577521 | [2] | NUT,M12 x 1.75 | LEC |
| 4. | 11114831 | [2] | BOLT,Hex, M12 x 130, 10.9 | LEC Superseded by part number: 9847703 |
| 5. | 76031591 | [4] | WASHER | LEC |
| 6. | 12164521 | [16] | NUT,Hex, M24, 2mm Pitch,19mm High, Cl 10 | MOD24X2X19 Superseded by part number: 12164527 |
| 7. | 14497331 | [16] | WASHER,25mm ID x 44mm OD x 4mm Thk | LEC24X44 Superseded by part number: 86511328 |
| 8. | 76045679 | [16] | STUD | LEC24X105 |
| 9. | 76031517 | [2] | BLOCK | LEC |
| 10. | 70900368 | [4] | NUT | LEC |
