纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.523[04]) - RIPPER (RP) - 'RECO' - OPTIONAL CODE 784117041 - VERSION (01-02-04) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
842 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76031532 | [2] | BUSHING | LEC- ASSY |
| 2. | 76089260 | [1] | BARREL | LEC Superseded by part number: 76031593 |
| 3. | 77904536 | [1] | NUT | LEC |
| 4. | 76031594 | [1] | PISTON | LEC |
| 5. | 76031595 | [1] | SEAL | LEC Superseded by part number: 76031598 |
| 6. | 14463680 | [1] | O-RING,0.139" Thk x 1.234" ID, -218, Cl 5, 75 Duro | TTF Superseded by part number: 14463681 |
| 7. | 76031537 | [1] | O-RING | LEC Superseded by part number: 76031545 |
| 8. | 76031538 | [1] | SEAL | LEC Superseded by part number: 76031545 |
| 9. | 76031539 | [1] | SEAL | LEC Superseded by part number: 76031545 |
| 10. | 76031541 | [1] | SEAL | LEC Superseded by part number: 76031545 |
| 11. | 76031542 | [1] | MUDSCRAPER RING | LEC Superseded by part number: 76031545 |
| 12. | 76089265 | [1] | BASE PLATE | LEC Superseded by part number: 76031543 |
| 13. | 15224131 | [4] | BOLT,Hex, M20 x 70mm, Cl 10.9, Full Thd | LEC Superseded by part number: 412641 |
| 14. | 14497131 | [4] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
| 15. | 76089266 | [1] | ROD | LEC Superseded by part number: 76031544 |
| 16. | 76031546 | [1] | BUSHING | LEC |
| 17. | 13407211 | [1] | LUBE NIPPLE,M10 x 1 | TTF Superseded by part number: 84351730 |
| 18. | 70921565 | [4] | SCREW | LEC Superseded by part number: 20988 |
| 19. | 70930370 | [4] | WASHER,0.44" ID x 0.69" OD x 0.11" Thk | BHB |
| 20. | 76089268 | [1] | RIGID TUBE | LEC Superseded by part number: 76031547 |
