凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (14.05) - LACED CHEVRON BELT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
382 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87056535
|
[6] |
BELT,177.80 mm W x 10681.00 mm L
|
PA
Laced Chevron
|
| 2. |
9843258
|
[12] |
TUBE
|
NH
|
| 3. |
9843257
|
[6] |
CABLE
|
NH
|
| 4. |
87343637
|
[1] |
REPAIR KIT
|
PA
Lacing Cable, Heavy Duty, Includes: (5') Lacing Cable, (20) Retainers Superseded by part number: 84134363
|
| 5. |
9847138
|
[1] |
REPAIR KIT
|
NH
Lacing, Includes: Box of 18 Cards, 45 Hooks per Card
|
| 6. |
86637506
|
[1] |
GUIDE
|
NH
Belt, Optional Superseded by part number: 84394681
|
| 7. |
811-10030
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 8. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 9. |
825-2410
|
[4] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
