纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.651[06]) - ROPS CANOPY - DASHBOARD - OPTIONAL CODE 784111201 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
914 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76067611 | [1] | DASH PANEL | LEC Superseded by part number: 76301226 |
| 2. | 76067780 | [1] | WIRE HARNESS | LEC |
| 3. | 76067458 | [4] | | |
| 4. | 13274617 | [16] | SCREW,Pozidriv Pan Hd, M5 x 25mm | LEC |
| 5. | 14496307 | [16] | WASHER,5.3mm ID x 10mm OD x 1mm Thk | LEC Superseded by part number: 14496321 |
| 7. | 4417913 | [1] | CONTAINER | BUR |
| 8. | 76067627 | [1] | PLATE | LEC |
| 9. | 76067737 | [1] | HOOK | LEC |
| 10. | 10902424 | [4] | SCREW,Hex, M6 x 20mm, Cl 8.8, Full Thd | TTF Superseded by part number: |
| 11. | 14496404 | [4] | WASHER,M6 x 12 x 2 Thk | TTF Superseded by part number: 17094724 |
| 12. | 76067746 | [1] | GASKET | LEC |
