| 1. |
87054697
|
[1] |
SHEET ASSY.
|
PA
RH Superseded by part number: 87661897
|
| 2. |
87046080
|
[2] |
ANGLE
|
PA
|
| 3. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Counter, Electric Wrap
|
| 5. |
86643977
|
[3] |
ANTI-SKID STRIP,4” x 40”, Black
|
NH
|
| 8. |
87017062
|
[1] |
FLOOR
|
PA
|
| 10. |
87041094
|
[1] |
SHIELD
|
PA
Rubber
|
| 11. |
87054696
|
[1] |
SHEET ASSY.
|
PA
LH Superseded by part number: 87661899
|
| 17. |
9804256
|
[1] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 19. |
844-8020
|
[12] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 20. |
811-8020
|
[9] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 22. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 23. |
322358
|
[16] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 24. |
80664
|
[14] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 26. |
9804276
|
[1] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 27. |
825-2408
|
[17] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 29. |
832-46408
|
[8] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 37. |
87560382
|
[1] |
DOOR
|
NH
Electric Wrap, Europe, No Decals Included.
|
| 38. |
86511841
|
[7] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
