| 1. |
86634020
|
[1] |
WIRE ROPE
|
NH
|
| 2. |
86636629
|
[1] |
SPACER
|
NH
|
| 3. |
696365
|
[3] |
SPACER
|
NH
|
| 4. |
689986
|
[4] |
ANGLE
|
NH
|
| 5. |
86632175
|
[1] |
WIRE ROPE
|
NH
|
| 6. |
9612212
|
[2] |
INDICATOR
|
NH
|
| 7. |
86509848
|
[1] |
SPRING
|
NH
Extension Superseded by part number: 217208
|
| 8. |
514042
|
[1] |
SPRING
|
NH
Extension
|
| 9. |
9619090
|
[2] |
CAP COVER
|
NH
|
| 10. |
144403
|
[1] |
EYEBOLT
|
NH
G2, 5/16"-18 x 4-1/4"
|
| 11. |
133095
|
[1] |
SPACER,10.32mm ID x 15.85mm OD x 7.9mm L
|
NH
|
| 12. |
510932
|
[3] |
PULLEY,50.01mm OD
|
NH
|
| 13. |
86632200
|
[1] |
PLATE
|
PA
Superseded by part number: 87025227
|
| 14. |
280299
|
[2] |
WASHER,0.19" ID x 0.44" OD x 0.05" Thk
|
NH
|
| 15. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 16. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 17. |
844-6016
|
[2] |
BOLT,Hvy Hex, M6 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 9804255
|
| 18. |
844-6030
|
[2] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86511839
|
| 20. |
844-8020
|
[4] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 21. |
9804260
|
[2] |
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
|
NH
|
| 22. |
814-8070
|
[1] |
BOLT,Hex, M8 x 1.25 x 70mm, Cl 8.8
|
CAS
Superseded by part number: 7120024
|
| 23. |
844-10030
|
[1] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 24. |
281020
|
[2] |
SELF-TAP SCREW,Pan HD, #8 - 18 x 3/4"
|
NH
|
| 25. |
425-285
|
[2] |
FLANGE NUT,Flg, 5/16"-18, G5
|
CAS
Superseded by part number: 86521605
|
| 26. |
825-2406
|
[6] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 27. |
825-2408
|
[8] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 28. |
825-2410
|
[1] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
