纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.653[10]) - ROPS CAB - DOOR - OPTIONAL CODE 784110251 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
977 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76301284 | [1] | WIPER MOTOR | LEC24V Left hand |
| 1. | 76301306 | [1] | WIPER MOTOR | LECRight hand |
| 2. | 76048974 | [2] | WIPER ARM | BUR |
| 3. | 76048863 | [2] | WIPER BLADE | LEC |
| 4. | 87400976 | [2] | | |
| 5. | 87400797 | [2] | PLATE | BUR |
| 6. | 87400795 | [2] | BUSHING | BUR |
| 7. | 10902221 | [3] | BOLT,Hex, M6 x 16mm, CL 8.8 | BHB Superseded by part number: |
| 8. | 14496431 | [3] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 9. | 10523401 | [1] | WASHER,6.15mm ID x 18mm OD x 2mm Thk | BAS |
| 10. | 87400794 | [2] | BUSHING | BUR |
| 12. | 14496531 | [3] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 16. | 76045509 | [4] | GROMMET | LEC |
| 18. | 16100811 | [2] | NUT,Hex, M8, 6.80mm, Cl 8, ZND | TTF Superseded by part number: 43362 |
| 19. | 14496501 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | TTF Superseded by part number: 86624184 |
