凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (18.03) - DIA KIT, PTO SUPPORT KIT, EUROPE & R.O.W. Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
308 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87529330
|
[1] |
DIA KIT, HARVESTER
|
PA
PTO Support, Includes: Installation Instructions
|
| 2. |
86619421
|
[1] |
ROD
|
NH
|
| 3. |
86977230
|
[1] |
PLATE
|
NH
|
| 4. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 5. |
280251
|
[1] |
COTTER PIN,3/32" OD x 1" OAL
|
BHB
|
| 6. |
81541
|
[2] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
|
| 7. |
86622500
|
[2] |
WASHER,13.49mm ID x 22.2mm OD x 1.36mm Thk
|
PA
|
| 8. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 9. |
87017977
|
[1] |
PLATE
|
PA
Trough
|
