凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (18.86[2]) - DIA KIT, DENSITY CYLINDER SYSTEM PRE-CHARGE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
504 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84548403
|
[1] |
SUPPORT
|
NH
|
| 2. |
84533319
|
[1] |
MOUNT
|
NH
|
| 3. |
87750434
|
[1] |
CLAMP
|
FAR
|
| 4. |
84532089
|
[1] |
ACCUMULATOR
|
NH
Diaphragm, 0.32L
|
| 5. |
195492
|
[1] |
ADAPTER,3/4" - 16 ORB x 9/16" - 18
|
NH
|
| 6. |
86836953
|
[1] |
ELBOW,9/16" - 18 ORB x 9/16" - 18 ORB
|
BEL
90°, -6 ORB. Female
|
| 7. |
9846669
|
[1] |
HYD CONNECTOR,9/16" - 18 Male x 9/16" - 18 Male
|
NH
Union, Straight Thread
|
| 8. |
84563959
|
[1] |
MANIFOLD
|
NH
8SZ, 2-Way, 2-Pos.
|
| 9. |
76350
|
[1] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
|
| 10. |
86643513
|
[1] |
HOSE,0.38" ID x 24.00", SAE 100R17
|
NH
|
| 11. |
87267034
|
[1] |
ORIFICE,9/16" - 18 Male JIC x 9/16" - 18 Female JIC, 1.91mm ID
|
BN
6FJ x 6MJ w/ 1,91 Orifice
|
| 12. |
86511840
|
[2] |
BOLT,Hex Flng, M6 x 1 x 40mm, Cl 8.8
|
NH
|
| 13. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 14. |
353308
|
[2] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 15. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 16. |
86511842
|
[1] |
BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8
|
NH
|
| 17. |
9671714
|
[2] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 18. |
86511841
|
[1] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 19. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 20. |
84532081
|
[1] |
INSTRUCTION
|
NH
Density Pre-Charge Kit Superseded by part number: 84531905
|
