| 1. | 510204 | [1] | O-RING,0.21" Thk x 2.6" ID, -334, Cl 5, 75 Duro | WIN |
| 2. | 11116021 | [24] | SCREW,Hex, M14 x 45mm, Cl 8.8, Full Thd | MKT Superseded by part number: 87015765 |
| 3. | 87016615 | [24] | WASHER,15.3mm ID x 28.5mm OD x 3mm Thk | RAC |
| 4. | L14386 | [2] | CLAMP | CAS Superseded by part number: 70921599 |
| 5. | 76044748 | [8] | FLANGE | LEC Superseded by part number: 71444029 |
| 6. | 238-6220 | [4] | O-RING,0.139" Thk x 1.359" ID, -220, Cl 6, 90 Duro | CAS Superseded by part number: 70925934 |
| 7. | 84556068 | [1] | HYDRAULIC HOSE,25.4mm ID x 751mm L, SAE 100R15 | BURPump to Motor Superseded by part number: 47525726 |
| 8. | 84498527 | [1] | HYDRAULIC HOSE,25.4mm ID x 1325mm L, SAE 100R1 | BURMotor to Manifold |
| 9. | 84386538 | [1] | HYDRAULIC HOSE,9.53mm ID x 524mm L, SAE 100R16 | BURPump to Manifold |
| 10. | 84386539 | [1] | HYDRAULIC HOSE,15.88mm ID x 624mm L, SAE 100R16 | BURPump G to Manifold P |
| 11. | 84498522 | [1] | HYDRAULIC HOSE,25.4mm ID x 608mm L, SAE 100R1 | BURPump T1 to Manifold TP2 |
| 12. | 86511661 | [2] | 90 ELBOW,Adj, 1 7/16"-12 ORFS x 1 5/8"-12" ORB | GI90 Deg |
| 13. | 84498524 | [1] | HYDRAULIC HOSE,25.4mm ID x 758mm L, SAE 100R1 | BURPump T2 to Manifold TP1 |
| 14. | 84498526 | [1] | HYDRAULIC HOSE,19.05mm ID x 1060mm L, SAE 100R1 | BURPump Drain to Manifold Superseded by part number: 47473631 |
| 15. | 87303844 | [4] | HYD CONNECTOR,1-7/16" - 12 ORFS x 1-1/16" - 12 ORB | WIC |
| 16. | 238-6219 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | CAS Superseded by part number: 86529541 |
| 17. | 9628065 | [16] | SCREW,Hex, M12 x 1.75 x 45mm, Cl 8.8 | NH |
| 18. | 86625255 | [16] | WASHER,13.3mm ID x 24.5mm OD x 3mm Thk | GI |
| 19. | 86980732 | [8] | CLAMP | GI |
| 20. | 9840325 | [2] | HYD CONNECTOR,1 11/16"-12 ORFS x 1 5/8"-12 ORB | WIN |
| 21. | 87351379 | [2] | HYD CONNECTOR | ZED10ORFSX3/4-16 ORB |
| 22. | 84574176 | [1] | HYDRAULIC HOSE,25.4mm ID x 805mm L, SAE 100R15 | BURFront Pump to LH Motor Superseded by part number: 47525726 |
