| 1. |
87347870
|
[1] |
DIA KIT, HARVESTER
|
PA
Incl 2 - 23
|
| 2. |
87684215
|
[1] |
INSTRUCTION
|
PA
|
| 3. |
9706748
|
[1] |
CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 4. |
173011
|
[1] |
GROMMET,1” ID x 1.750” OD x .500” Tk
|
NH
|
| 5. |
87017806
|
[1] |
DUST CAP,Green
|
PA
Superseded by part number: 84819677
|
| 6. |
263117
|
[6] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
|
| 7. |
87016310
|
[1] |
SPACER
|
PA
|
| 8. |
86836356
|
[1] |
HOSE,9.53mm ID x 4673.6mm L, SAE 100R17
|
NH
|
| 9. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
|
| 10. |
261066
|
[1] |
ORIFICE,9/16" - 18, 0.813" Orifice
|
NH
|
| 11. |
87056843
|
[1] |
HYDRAULIC CYLINDER,38.1mm Rod, 76.2mm Stroke
|
PA
Superseded by part number: 47583052
|
| 12. |
86705824
|
[1] |
CHANNEL
|
NH
|
| 13. |
514112
|
[1] |
PIN
|
NH
|
| 14. |
9671714
|
[3] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 15. |
309308
|
[1] |
BOLT,Hex, M12 x 1.75 x 120mm, Cl 8.8
|
NH
|
| 16. |
86611401
|
[5] |
WASHER,25.53mm ID x 31.24mm OD x 1.65mm Thk
|
NH
|
| 17. |
86637848
|
[1] |
WASHER,13.5mm ID x 38.1mm OD x 3.68mm Thk
|
NH
|
| 18. |
27318
|
[1] |
WASHER,26mm ID x 51mm OD x 1.5mm Thk
|
NH
|
| 19. |
87367
|
[2] |
WASHER,1.06" ID x 2" OD x 0.13" Thk
|
PA
|
| 20. |
322358
|
[3] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 21. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 22. |
9804277
|
[3] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 23. |
80754
|
[1] |
COTTER PIN,3/16" OD x 1-1/2" OAL
|
NH
|
