斗山零件查询MAIN PIPING(5) - ARM & BUCKET DX300LC-5(S/N:1001~1057) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
867 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-08516
|
[-] |
|
|
| 1. |
DS2040836
|
[1] |
|
|
| 101. |
110420-00179E
|
[1] |
|
|
| 102. |
110420-00178E
|
[1] |
|
|
| 103. |
S0515466
|
[4] |
BOLT
|
|
| 104. |
4114-1792A
|
[4] |
WASHER
|
|
| 2. |
DS2040837
|
[1] |
|
|
| 3. |
DS2040838
|
[1] |
|
|
| 4. |
2181-1950D9
|
[1] |
PLUG
|
|
| 5. |
2180-1026D19
|
[6] |
O-RING
|
|
| 52. |
DS2040835
|
[1] |
|
|
| 53. |
DS20401342
|
[1] |
|
|
| 54. |
2181-9081
|
[2] |
FLANGE;SPLIT
|
|
| 55. |
2181-9083
|
[2] |
FLANGE;SPLIT
|
|
| 56. |
2181-1950D1
|
[1] |
PLUG
|
|
| 57. |
S2212266
|
[4] |
BOLT
|
|
| 58. |
S2215466
|
[4] |
BOLT
|
|
| 59. |
2180-1026D19
|
[3] |
O-RING
|
|
| 6. |
S8000291
|
[1] |
O-RING
|
|
| 60. |
S8000111
|
[1] |
O-RING
|
|
