| 1. | 627-16035 | [4] | BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86529976 |
| 2. | 627-16045 | [2] | BOLT,Hex, M16 x 2 x 45mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86508624 |
| 3. | 80710 | [6] | LUBE NIPPLE,1/8" - 27 | DUB |
| 4. | 374835 | [2] | BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd | BHB |
| 5. | 412087 | [2] | BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd | BHB Superseded by part number: 86639031 |
| 6. | 47374510 | [2] | HYD. TUBE | BURLift Rod End |
| 7. | 47375141 | [1] | HYD. TUBE | BURLift Cylinder Head End, Left Hand |
| 8. | 47375290 | [2] | HYDRAULIC HOSE,19.05mm ID x 895mm L, SAE 100R16 | BURLower Port |
| 9. | 47375292 | [2] | HYDRAULIC HOSE,19.05mm ID x 1105mm L, SAE 100R16 | BURLift Rod End |
| 10. | 47375372 | [1] | HYD. TUBE | BURLift Cylinder Head End, Right Hand |
| 11. | 84385169 | [4] | BUSHING,52.32mm ID x 57.15mm OD x 15.75mm L | BURSpacer |
| 12. | 84405556 | [5] | CLAMP | BURCylinder Saddle |
| 13. | 84409094 | [4] | PIN,50.83mm OD x 137.6mm L | BURBlade Lift Cylinder Superseded by part number: 47652409 |
| 14. | 84409095 | [4] | SPECIAL WASHER | BURPin Clip |
| 15. | 84467808 | [2] | CLEVIS | BURLift Cylinder |
| 16. | 84568811 | [1] | PIN,50.75mm OD x 198mm L | BURLift Cylinder |
| 17. | 84569321 | [1] | RETAINER | BURLoop |
| 18. | 84570110 | [1] | GUARD | BUR Superseded by part number: 47571859 |
| 19. | 84576004 | [1] | BRACKET | BURHose |
| 20. | 84580669 | [1] | HYD. TUBE | BURTilt Tube End |
| 21. | 84580670 | [1] | HYD. TUBE | BURTilt Rod End |
| 22. | 84580680 | [1] | HYDRAULIC HOSE,19.05mm ID x 658mm L, SAE 100R16 | BURTilt Cylinder End |
| 23. | 84580677 | [1] | HYDRAULIC HOSE,19.05mm ID x 746mm L, SAE 100R16 | BURTilt Rod End |
| 24. | 84591656 | [1] | HYDRAULIC HOSE,15.88mm ID x 2885mm L, SAE 100R16 | BURTilt Rod End |
| 25. | 84591657 | [1] | HYDRAULIC HOSE,15.88mm ID x 2975mm L, SAE 100R4 | BURTilt Tube End |
| 26. | 86624946 | [70] | BALL,3/4" Dia | RAC |
| 27. | 86639062 | [1] | BHD LOCK NUT,1-3/16"-12 ORFS, Bulkhead | FAR |
| 28. | 86639085 | [1] | BHD LOCK NUT,1"-14, Bulkhead | FAR |
| 29. | 86639209 | [3] | BOLT,M8 x 1.25 x 40.45mm, Cl 10.9 | FAR |
| 30. | 87028944 | [1] | ELBOW,90°, 1"-14 ORFS, Bulkhead | GI |
| 31. | 87019670 | [4] | HOSE CLAMP,#80, 4.62/5.50 Type F Worm | RAC |
| 32. | 86837484 | [1] | ELBOW,90º, 1 3/16"-12. ORFS, Blkhd | CAS |
| 33. | 87378036 | [4] | ELBOW | RAC90 Degree, ORFS 12 |
| 34. | 87655043 | [4] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BURM12 x 13.65 x 24.9 x 3.2 HTS Boron |
| 35. | 87656136 | [6] | HYD CONNECTOR | BHB90 ADJ -12 ORFS x 7/8-14 ORB |
| 36. | 87690486 | [1] | CLAMP,149mm ID - 172mm ID, SAE #100 | GI#100 5.88/6.75 Type F Worm Gear H |
| 37. | 87713133 | [2] | SPECIAL WASHER | BURM16 x 17.75 x 31.5 x 4.2 Hts Boron |
| 38. | 419041A1 | [2] | SPACER | BURBolt |
| 39. | 419223A1 | [2] | WASHER | BUR |
| 40. | D28481 | [2] | PLUG | CASSpecial |
