神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (01-001) - CYLINDER BLOCK Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
860 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | CYLINDER BLOCK(M0) | |
| . . | 6D22Z ALL | [1] | CYLINDER BLOCK(M0) | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKCASE |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG FR |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO.2 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG MI |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG RE |
| 6. | VAME061330 | [14] | SCREW | KOBBOLT Superseded by part number: 132340A1 |
| 7. | VAME051220 | [6] | LINER | KOBLINER, CYL A SIZE Superseded by part number: 132312A1 |
| . . | VAME051221 | [1] | LINER, ENGINE CYLIND | KOBB SIZE Superseded by part number: 132313A1 |
| . . | VAME051222 | [1] | C SIZE | |
| 8. | VAME051375 | [6] | O-RING | KOBO-RING Superseded by part number: VAME151038 |
| 9. | VA3090722300 | [6] | SEAL KIT | KOBRUBBER Superseded by part number: 132311A1 |
| 10. | VA3110702401 | [12] | O-RING | KOB Superseded by part number: 3110702401 |
| 11. | VAMS666137 | [1] | CAP | KOBCAP, SEARING |
| 12. | VAMH007009 | [2] | PIN | KOBPIN, DOWEL 8 |
| 13. | VAMH007011 | [2] | PIN | KOBPIN, DOWEL 12 Superseded by part number: 132324A1 |
| 15. | VAME051187 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO.1 |
| 16. | VAME051188 | [1] | BUSHING | KOBBUSHING, CAMSHAFT N0.2 |
| 17. | VAME051189 | [2] | BUSHING | KOBBUSHING, CAMSHAFT NO.3,4 |
| 18. | VAME051190 | [2] | BUSHING | KOBBUSHING, CAMSHAFT NO.5,6 |
| 19. | VAME051191 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO.7 |
| 20. | VA3090715800 | [7] | SET OF SCREWS | KOBSCREW, SET |
| . . | VAMF660063 | [7] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 21. | VAME031518 | [6] | VALVE VALVE, CHECK | VALVE VALVE, CHECK |
| 22. | VAME051197 | [6] | JET | KOBBODY, OIL JET |
| 23. | VAME031086 | [6] | WASHER | KOBWASHER, LOCK |
| 24. | VAMH012037 | [6] | PIN | KOBPIN, SPG 5X10 Superseded by part number: 132322A1 |
| 25. | VAMH037137 | [2] | PLUG | KOBPLUG 20 |
| . . | VAMH035077 | [2] | GASKET | KOBGASKET 20 |
| 26. | VA3090702800 | [1] | PLUG | SMPLUG 10 |
| 27. | VAME031088 | [3] | PLUG | KOBPLUG |
| 28. | VAMF665539 | [1] | CAP | KOBCAP, SEALING 28 Superseded by part number: 132331A1 |
| 29. | VAMF472405 | [14] | DOWEL | KOBPIN, DOWEL 10 Superseded by part number: 132323A1 |
| 30. | VAMF406288 | [2] | STUD | SMSTUD 10X30 |
| 31. | VAMF472406 | [2] | PIN | KOBPIN, DOWEL 12 |
| 32. | VAMF472404 | [4] | DOWEL | KOBPIN Superseded by part number: MF472404 |
