| 1. | 608-20080 | [36] | BOLT,Hex, Lock, M20 x 80, Cl 10.9 | RAC Superseded by part number: 87371130 |
| 2. | 43140 | [16] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8 | NH |
| 3. | 337476 | [4] | BOLT,Hex, M12 x 1.75 x 50mm, Cl 10.9 | WIN |
| 4. | 412398 | [12] | BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd | NH |
| 5. | 9706702 | [8] | BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8 | NH |
| 7. | 47466858 | [2] | FINAL DRIVE | BURFender |
| 7. | 47466858R | [2] | REMAN-FINAL DRIVE | RACD150C WT/LGP, D150C XLT, Both CRAWLER DOZER - TIER 4A, FRAMES & BALLSTING (10/13-) |
| 7. | 47466858C | [2] | CORE-FINAL DRIVE | RACReturn Number |
| 8. | 84375567 | [2] | COVER | BURFender |
| 9. | 84375837 | [1] | PLATE | BUROil Drain Cover |
| 10. | 84381503 | [1] | PLATE | BURCenter Box |
| 11. | 84530201 | [1] | COVER PLATE | BURBelly Pan |
| 12. | 84530204 | [1] | COVER PLATE | BURFront Belly Pan |
| 13. | 84544923 | [2] | PLATE | BURRear Belly Pan |
| 14. | 84578277 | [2] | COVER | BURPainted |
| 15. | 86639036 | [2] | BOLT,Hex, M24 x 60mm, Cl 10.9, Full Thd | FAR |
| 16. | 86837482 | [8] | BOLT,Hex, M16 x 55, 10.9, Full Thd | GI |
| 17. | 87016608 | [2] | WASHER,25.8mm ID x 44.5mm OD x 5mm Thk | RAC |
| 18. | 87447306 | [12] | SQUARE NUT | CASM12 x 1.75, Square |
| 19. | 87655043 | [12] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BURM12, 13.65 x 24.9 x 3.2 |
| 20. | 87655044 | [20] | SPECIAL WASHER,17.75mm ID x 31.50mm OD x 4.20mm, HTS Boron, ZNM | BURM16, 17.75 x 31.5 x 4.2 |
| 21. | 87655046 | [16] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BURM10, 10.65 x 23.0 x 2.2 |
| 22. | 87655047 | [36] | SPECIAL WASHER,21.25mm ID x 38.10mm OD x 4.20mm, HTS, BORON | BURM20, 21.25 x 38.1 x 4.2 |
| 23. | 336371A1 | [32] | PIN | CASNut Retainer |
| 24. | 405737A2 | [20] | SQUARE NUT | BURM16 x 2, Square |
