神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (01-018[01]) - TURBO-CHARGER, GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
640 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | TURBOCHARGER GENERAL(M3) | |
| 1. | VAME058448 | [1] | TURBOCHARGER | KOBASSY 3LM319 |
| 4. | VA3003291200 | [1] | GASKET | KOB Superseded by part number: VAME150877 |
| 6. | VAMH004106 | [8] | NUT 10 | NUT 10 |
| 7. | VAME058625 | [1] | PIPE | KOBINLET |
| 7A. | VAME031087 | [1] | SET OF SCREWS | KOBPLUG |
| . . | VAMF660063 | [1] | GASKET | KOB10 Superseded by part number: VAF420210000 |
| 9. | VAMH000245 | [4] | BOLT | KOBW/WSR 10X58 |
| 10. | VA3014000900 | [4] | BOLT 10X125 | BOLT 10X125 |
| . . | VAMF450406 | [4] | WASHER | KOBSPG 10 |
| . . | VAMF450006 | [4] | NUT | KOBPLAIN 10 Superseded by part number: 133247A1 |
| 11. | VAME053453 | [1] | HOSE | KOBRUBBER |
| 12. | VAMH021321 | [2] | CLAMP | KOBHOSE Superseded by part number: 134981A1 |
| 15. | VAME058681 | [1] | COUPLER,INLET | COUPLER,INLET |
| 16. | VA3003096800 | [1] | HOSE, BULK | KOBHOSE, METERS |
| 17. | VA3123011830 | [1] | CLAMP | KOB Superseded by part number: 134980A1 |
| 18. | VA3123011840 | [1] | CLAMP | KOBHOSE Superseded by part number: 134979A1 |
| 20. | VA3003291300 | [1] | HINGE | KOBJOINT, TURBINE |
| 21. | VAME063946 | [2] | SEAL RETAINER | KOB Superseded by part number: 134995A1 |
| 27. | VAMC820467 | [2] | SPACER T=3.2 | |
| 50. | VAME058926 | [1] | PIPE | KOBINLET |
| 53. | VA3093690900 | [2] | CLAMP | KOB |
| 54. | VA3127516500 | [1] | SPACER | KOBL=20 |
| 55. | VAME920004 | [1] | SPACER | KOBL=5 |
| 56. | VAMH022152 | [2] | OIL SEAL | KOBPROTECTOR, RUBBER |
| 60. | VAMH037254 | [1] | BOLT | KOBEYE |
| 64. | VAME058968 | [1] | PIPE | KOB |
| 67. | VAMF300841 | [1] | SCREW | KOBW/WSR10X20 Superseded by part number: 132461A1 |
| 68. | VA3123612600 | [1] | GASKET | KOB Superseded by part number: 133176A1 |
| 69. | VAMH000886 | [2] | BOLT 3/8-16UNC | BOLT 3/8-16UNC |
| 70. | VAME054279 | [1] | HOSE | KOBRUBBER |
| 71. | VAMF661017 | [2] | CLAMP HOSE 33 | CLAMP HOSE 33 |
| 72. | VAME058819 | [1] | PIPE | KOB |
| 73. | VA3094291400 | [1] | GASKET | KOB |
| 74. | VAMF300841 | [2] | SCREW | KOBBOLT, W/WSR 10X20 Superseded by part number: 132461A1 |
