神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (01-019) - TURBO-CHARGER, INNER PART Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
722 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | TURBO CHARGER INNER PART(M1) | |
| 1-26. | VAME058448 | [1] | TURBOCHARGER | KOBASSY 3LM319 |
| 1. | VAME719370 | [1] | COVER, COMPR | |
| 2. | VAME719272 | [1] | PLATE CLAMP | PLATE CLAMP |
| 3. | VAME719390 | [8] | CAP SCREW & LOCK WASHER ASSY | |
| . . | VAME719382 | [1] | LOCK NUT | KOB |
| 5. | VAME719360 | [1] | WHEEL, COMPR | |
| 6. | VAME719126 | [1] | RING SNAP | RING SNAP |
| 7. | VAME719338 | [1] | INSERT | INSERT |
| 8. | VAME719127 | [1] | O-RING | KOB |
| 9. | VAME719339 | [2] | SET OF RINGS | KOB |
| 10. | VAME719270 | [1] | DEFLECTOR, OIL | |
| 11. | VAME719381 | [1] | SLEEVE THRUST | SLEEVE THRUST |
| 12. | VAME719337 | [1] | THRUST BEARING | KOBBEARING, THRUST |
| 12A. | VAME719383 | [1] | RING | KOBTHRUST |
| 13. | VAME719336 | [1] | BALL BEARING | KOB |
| 14. | VAME719300 | [1] | HOUSING, TURBINE | |
| 15. | VAME719326 | [2] | LOCKING PLATE | KOB |
| 16. | VAME719327 | [2] | PLATE LOCK | PLATE LOCK |
| 17. | VAME719325 | [4] | SCREW | KOBCAP |
| 18. | VAME719350 | [1] | SHAFT & TURBINE WHEEL ASSY | |
| 19. | VAME719290 | [1] | SET OF RINGS | KOB |
| 20. | VAME719323 | [1] | PLATE | KOBTURBINE BACK |
| 21. | VAME719328 | [1] | GASKET | KOB |
| 23. | VAME719340 | [1] | BALL BEARING | KOBHOUSING & PIN ASSY |
| 25. | VAME719392 | [1] | PLATE, NAME | |
| 26. | VAME719043 | [1] | SCREW, SELF TAPPING | |
