神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (03-007) - FUEL INJECTION, PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
627 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | FUEL INJECTION PIPE(M0) | |
| . . | 6D22Z ALL | [1] | FUEL INJECTION PIPE(M0) | |
| 1. | VAME056361 | [1] | INJECTION PIPE | KOBINJECTION N0.1 |
| 2. | VAME056362 | [1] | INJECTION PIPE | KOBINJECTION NO.2 |
| 3. | VAME056363 | [1] | PIPE | KOBINJECTION NO.3 |
| . . | VAME056364 | [1] | INJECTION PIPE | KOBINJECTION NO.4 |
| 5. | VAME056365 | [1] | PIPE | KOBINJECTION NO.5 |
| 6. | VAME056366 | [1] | PIPE | KOBINJECTION NO.6 |
| . . | VA3096101309 | [1] | PIPE INJECTION STRAIGHT D6X2 L640 (FOR SERVICE ONLY) | PIPE INJECTION STRAIGHT D6X2 L640 (FOR SERVICE ONLY) |
| 7. | VAMH020258 | [8] | CLAMP | KOB Superseded by part number: 134717A1 |
| 9. | VAMH021250 | [2] | CLAMP | KOB |
| 10. | VAMH021251 | [2] | CLAMP | KOB |
| 12. | VAMF240029 | [8] | SCREW | KOBW/WSR 6X25 |
