纽荷兰零件查询(D150C WT/LGP) - CRAWLER DOZER - TIER 4A (10/13-) (48.130.AW[02]) - ROCK GUARD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
777 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84411001 | [4] | GUARD | BURRock Superseded by part number: 47553793 |
| 2. | 87655047 | [40] | SPECIAL WASHER,21.25mm ID x 38.10mm OD x 4.20mm, HTS, BORON | BURM20 x 21.25 x 38.1 x 4.2 Hts Boron |
| 3. | 87560270 | [8] | BOLT,Hex, M20 x 330mm, Cl 8.8 | BUR |
| 4. | 87558879 | [8] | SPACER | BURRock Guard |
| 5. | 412180 | [8] | NUT,M20 x 2.5, Cl 8 | ZED Superseded by part number: 9672396 |
| 6. | 87563127 | [24] | BOLT,Hex, M20 x 50mm, Cl 10.9 | BHBLock M20 x 50 Full, 10.9 |
