神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (04-005) - ALTERNATOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
944 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CZ-KS06 | [1] | ALTERNATOR (INNER PARTS)(M4) | |
| . . | 6D221CZ-KS09 | [1] | ALTERNATOR (INNER PARTS)(M4) | |
| . . | 6D221CZ-KS07 | [1] | ALTERNATOR (INNER PARTS)(M4) | |
| . . | 6D221CZ-KS04 | [1] | ALTERNATOR (INNER PARTS)(M4) | |
| . . | 6D221CZ-KS01 | [1] | ALTERNATOR (INNER PARTS)(M4) | |
| . . | 6D221CT-KS03 | [1] | ALTERNATOR (INNER PARTS)(M4) | |
| . . | 6D221CZ-KS0A | [1] | ALTERNATOR (INNER PARTS)(M4) | |
| 1-26B. | VAME049154 | [1] | ALTERNATOR | KOBALTERNATOR ASSY 24V-30A |
| 1. | VAA529X05471 | [1] | NUT SET | NUT SET |
| 2. | VAA628T36771 | [1] | PULLEY | KOBCX2 |
| 3. | VAA414X14971 | [1] | SCREW | KOBSET |
| 4-6. | VAA640T27970 | [1] | BRACKET ASSY, FR | |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET, FR |
| 5. | VAA414X15071 | [1] | SCREW SET | SCREW SET |
| 6. | VAS930P37201 | [1] | BEARING | KOB Superseded by part number: VAME700535 |
| 7-8. | VAA880T22070 | [1] | ROTOR | KOB Superseded by part number: VAME700150 |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONROTOR |
| 8. | VAS930P33970 | [1] | BEARING | KOB |
| 13. | VAA383T20270 | [1] | AIR CONDITIONING STATOR | AIR CONDITIONING STATOR |
| 14-19. | VAA641T34670 | [1] | BRACKET | KOBRE |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET, RE |
| 15A. | VAA450X10571 | [1] | TERMINAL | KOBSET |
| 16. | VAA771S01017 | [1] | MOLD | MOLD |
| 16A. | VAA308D01501 | [1] | CONNECTOR | CONNECTOR |
| 16B. | VAS054S05083 | [1] | SCREW P 5X8 | SCREW P 5X8 |
| 17. | VAA414X17071 | [1] | SCREW SET | SCREW SET |
| 19. | VAA860T06870 | [1] | RECTIFIER ASSY | RECTIFIER ASSY |
| 20-22. | VAA866X01070 | [1] | REGULATOR | KOBASSY Superseded by part number: VAME700091 |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONREGULATOR |
| 21. | VAA648D01971 | [2] | BRUSH HOLDER | KOB Superseded by part number: VAMM502377 |
| 22. | VAA389D01901 | [2] | SPRING BRUSH | SPRING BRUSH |
| 26. | VAA210X91471 | [1] | COVER SET | COVER SET |
| 26B. | VAA981S60102 | [1] | BOLT | KOBW/WSR 6X12 |
