神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (06-006) - WATER SEPERATOR Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
939 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CZ-KS06 | [1] | WATER SEPERATOR(M2) | |
| . . | 6D221CZ-KS04 | [1] | WATER SEPERATOR(M1) | |
| . . | 6D221CZ-KS01 | [1] | WATER SEPERATOR(M1) | |
| 1-16. | VAME069670 | [1] | SEPARATOR | KOBWATER ASSY (FOR M1) Superseded by part number: VAME158071 |
| . . | VAME059754 | [1] | SEPARATOR | KOB(FOR M2) |
| 1. | VAME069672 | [1] | COVER | KOB |
| 2. | VAME060628 | [1] | CASE WATER SEP | CASE WATER SEP |
| . . | VAME059640 | [1] | PLATE, CAUTION | |
| 3. | VAME060603 | [1] | NUT, RING | NUT, RING |
| 4. | VAME069680 | [1] | O-RING | KOBCASE Superseded by part number: 133377A1 |
| 5. | VAME069675 | [1] | PLATE,BAFFLE | PLATE,BAFFLE |
| 6. | VAME069679 | [1] | GASKET | KOB |
| 7. | VAME069676 | [1] | PLATE | KOBISOLATION |
| 8. | VAME069671 | [1] | SCREEN | KOB Superseded by part number: 133382A1 |
| 9. | VAME069677 | [1] | FLOAT | KOBLEVELING, WATER Superseded by part number: VAME158038 |
| 10. | VAME016812 | [1] | PLUG | KOBDRAIN |
| 11. | VAMF520085 | [1] | O-RING | KOB10 Superseded by part number: VAF315101000 |
| 12. | VAMH037087 | [2] | BOLT | KOBCONNECTOR 14 |
| 13. | VAMH035069 | [4] | GASKET | KOB14 Superseded by part number: 133378A1 |
| 14. | VAMH037116 | [2] | FLEXIBLE JOINT | KOBSWIVELING (FOR M1) |
| 15. | VAMH037084 | [1] | GLOW PLUG | KOBAIR Superseded by part number: 77270641, VAME016894 |
| 16. | VAMH035067 | [1] | GASKET | KOB8 |
| 20. | VAME059566 | [1] | BRACKET, WATER SEPARATOR (FOR M2) | |
| 21. | VAMF241282 | [2] | BOLT | KOBW/WSR 10X25 (FOR M2) |
| . . | VAMF450006 | [2] | NUT | KOBWASHER, PLAIN 10 (FOR M2) Superseded by part number: 133247A1 |
| 22. | VAMC820467 | [1] | SPACER T=3.2 (FOR M2) | |
| 23. | VAMF300843 | [2] | SCREW | KOBW/WSR 10X25 (FOR M2) Superseded by part number: 133250A1 |
| 24. | VAME910156 | [1] | HOSE | KOBFEED (FOR M2) |
| 25. | VA3094290700 | [1] | STAY | KOB(FOR M2) |
| 26. | VAMH020807 | [1] | CLIP | KOBHOSE (FOR M2) |
| 27. | VAMF240023 | [1] | BOLT & WASHER ASSY 6X12 (FOR M2) | BOLT & WASHER ASSY 6X12 (FOR M2) |
| 28. | VA0303606600 | [1] | PIPE FUEL L=6000 (FOR M2) | PIPE FUEL L=6000 (FOR M2) |
| 29. | VAMS666005 | [4] | CLIP CLAMP, HOSE 15 (FOR M2) | CLIP CLAMP, HOSE 15 (FOR M2) |
