神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (08-002) - CYL HEAD, REPAIR KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
515 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | CYL.HEAD REPAIR KIT(M0) | |
| . . | 6D22Z ALL | [1] | CYL.HEAD REPAIR KIT(M0) | |
| 1-15. | VAME999365 | [6] | HEAD | KOB6D22 |
| 1. | NSS | [6] | NOT SOLD SEPARAT | CONHEA, CYL |
| 2. | VAME051300 | [6] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE SEAT INLET Superseded by part number: 132307A1 |
| 3. | VAME051034 | [6] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE SEAT EXH |
| 4. | VAME051120 | [6] | VALVE GUIDE | KOBINLET Superseded by part number: 132308A1 |
| 5. | VAME051122 | [6] | VALVE GUIDE | KOBEXH Superseded by part number: 132309A1 |
| 6. | VAMS666134 | [6] | CAP | KOBSEALING 18 |
| 7. | VAMS666135 | [12] | CAP | KOBSEALING 20 Superseded by part number: 132302A1 |
| 7A. | VAMH037729 | [6] | PLUG | KOBPLUG |
| 8. | VAMS666137 | [18] | CAP | KOBSEALING 25 |
| 9. | VAME062523 | [6] | SUPPORT | KOBDIRECTOR Superseded by part number: VAME051127 |
| 10. | VA3090113709 | [6] | NOZZLE | KOBTUBE Superseded by part number: 132294A1 |
| 11. | VAMH035157 | [6] | O-RING | KOBNOZZLE TUBE Superseded by part number: 132299A1 |
| 12. | VAMH002131 | [24] | STUD | KOB Superseded by part number: 132296A1 |
| 14. | VAMF472585 | [6] | SPRING | KOBPIN, SPG 6X12 |
| 15. | VAMH004054 | [24] | NUT | KOBSELF LOCK FLANGE Superseded by part number: 134868A1 |
